Connection
(1) ConnectthePCandbarcodereader.
(2)Connectthe232C(TTL)side4PPconnectoroftheUSB-232C(TTL)conversionjigtotheMAINPWBUNIT
(CON601)oftheset.
(3) ConnecttheUSBsideoftheUSB-232C(TTL)conversionjigtothePC.
Writin ne iht picup dt 
•Barcodepositionoflightpick-upunit
(1) SwitchonthepoweronofthesetbeforetheBDMECAUNITASSYisreplaced.
(2) DecompresstheDMScanBarcodeRpower2.16.60(ES460)MPfunction.ipfolderandstartthe"Rpower.ee".
(3) Apop-upisdisplayed.Click"O".
(4) Click"O".
PC(USB)へ
MAINPWBUNIT
CON601
4PRE-PCONNCORD(1000mm)
umperpin:3.3V
fmark
USB-232C(TTL)conversionsig
Viewfromthebottom
2-DimensionalBarCode
BDMECAUNITASSYforreplacement
(The2-dimensionalbarcodecanbephotographed
withadigitalcamera,andthebarcodedatacanbe
convertedwitha2-dimensionalbarcodereader.)
