Denon DBP-1611UD

9
1. FRONT PANEL ASSY
(1) DetachtheLOADERPANEL.
(2) DisconnecttheconnectorwireandFFCcable.
(3) Liftuptounhooktheclawandmoveinthedirectionofarrowtograduallypullouttheassembly.
Proceedin  TOP COVER
FRONT PANEL ASSY
→
Shootingdirection:B
4 FFCcable
Shootingdirection:D
Viewfromthebottom
Shootingdirection:C
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofeachP.W.BincludedinFRONTPANELASSY.
