18
DCD-1500AE
Table 3:Discdistinctioninformation
PIlevelFormula:PIlevel(V)=Measuredvalue × 1.6 ÷ 256
"-":Invalid
Table 4:Discclassificationinformation
MirrCount MirrWidth FZCCountPILevel
NoDisc Except2
and3
---
CDHigh
reflection
2Morethan
0x8ED
-Morethan
0x99
CDLow
reflection
2Morethan
0x8ED
-Lessthan
0x98
DVDHigh
reflection
2Lessthan
0x8ED
1Morethan
0x81
DVDLow
reflection
2Lessthan
0x8ED
1Lessthan
0x80
DVD2-layer 2 Lessthan
0x8ED
2-
SACDHybrid 3 - - -
DiscType Media
0x00 NoDisc
0x01 UnknownDisc
0x04 DVDSingleHighreflection
0x05 DVDDualParallelLowreflection
0x06 DVDDualOppositeLowreflection
0x08 CDDAHighreflection
0x0A VCDHighreflection
0x44 DVDSingleLowreflection
0x48 CDDALowreflection
0x4A VCDLowreflection
0x8F SACDHybridDisc
Table 5:HEAT RUN ERROR CODE
No Error contents FL Display
1 Tray Error ( Back End ) E1 ****
2 Bad Disc E2 ****
3 Focus Error E2 ****
4 Read Error E2 ****
5 Tracking Error E4 ****
6 Tray Error (Front End ) E5 ****
7 Navigation Pack Read Error E6 ****
8 Communication Error E7 ****
9 No Disc NO DISC ****
(**** ; Number of times to error generating. )
表 5ヒートランエラーコード表
No. エラー内容 FL 管表示
1 トレイエラー ( Back End )
E1 ****
2 不良ディスク
E2 ****
3 フォーカスエラー
E2 ****
4 リードエラー
E2 ****
5 トラッキングエラー
E4 ****
6 トレイエラー (Front End )
E5 ****
7 ナビゲーションパックエラー
E6 ****
8 コマンド通信エラー
E7 ****
9 ディスクが無い
NO DISC ****
(**** ; エラー発生までの回数 )
表3ディスク判別情報
PIlevel計算式:PIlevel(V)=測定値× 1.6 ÷ 256
"-" は無効
表4ディスク種別情報
MirrCountMirrWidth FZCCountPILevel
NoDisc 2 と 3 以外 - - -
CD 高反射 2 0x8ED 以上 - 0x99 以上
CD 低反射 2 0x8ED 以上 - 0x98 以下
DVD 高反射 2 0x8ED 以下 1 0x81 以上
DVD 低反射 2 0x8ED 以下 1 0x80 以下
DVD2 層 2 0x8ED 以下 2 -
SACDHybrid 3 - - -
DiscType Media
0x00 NoDisc
0x01 UnknownDisc
0x04 DVDSingle高反射
0x05 DVDDualParallel低反射
0x06 DVDDualOpposite低反射
0x08 CDDA高反射
0x0A VCD高反射
0x44 DVDSingle低反射
0x48 CDDA低反射
0x4A VCD低反射
0x8F SACDHybridDisc
