Denon DCD-1500AE - Loader Operation Waveforms; LD Signal Waveforms; Switch Signal Waveforms

75
DCD-1500AE
5. LOADER open-close
9 LD+
10 LD -
11 OPN SW
12 CLS SW
10 LOAD -
9 LOAD+
11 OPN SW
12 CLS SW
GND ; 16 GND GND ; 16 GND
OPEN CLOSE OPEN CLOSE
