DCD-1500AE
PARTS LIST OF P.W.B. UNIT
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
00D1U-3624C SACD MODULE P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC401 00D 262 3217 003 CXD2753R +C
IC402 00D 262 2875 006 16M SDRAM(TSOP)-7/8 +C
IC403 00D 262 3195 905 AD8062-SO8 +C
IC404 00D 262 3282 009 EMP3128ATC100-10(HARMONY-8LI)
IC501 00D 262 3219 001 CXD1881AR/BR +C
IC502 00D 262 3218 002 CXD1885Q +C
IC503 00D 262 3409 002 MSM51V18165F-50TSK-7
IC505 00D 263 1109 909 AN8471SA +C
IC507 00D 262 3201 909 TC7WH08FU-TE12L +REF
IC508 00D 262 3221 002 FAN8042 +C
IC701,702 00D 262 2977 946 BA33BC0FP-E2 +REF
IC703 00D 262 2977 904 BA18BC0FP-E2 +C
IC704 00D 263 1182 900 NJM2391DL1-26-TE1 +REF
IC706,707 00D 262 3203 907 TC7SHU04F-TE85L +REF
IC732 00D 262 3310 900 T14L1024N-12J(TAPE) +REF
IC733 00D 262 3206 904 S-80843CLNB-B64-T2 +C
IC739 00D 262 3529 018 M30625FGPGP-DE3112 *
TR511,512 00D 272 0166 905 2SB798(DL/DK)-T1 +C
D501 00D 276 0778 900 1SS300-TE85L +C
D701-704 00D 276 0717 903 1SS355 TE-17 +C
D731 00D 276 0717 903 1SS355 TE-17 +C
RESISTORS GROUP
RA401,402 00D 247 9003 908 MNR14=220JE0AB +C
RA501-504 00D 247 9007 917 MNR14=103JE0 +C
CAPACITORS GROUP
C403 nsp 00D 257 0512 903 CK73F1E104ZT +1608
C404 00D 254 4464 964 CE67C0J470MT(MV) +REF
C405 nsp 00D 257 0512 903 CK73F1E104ZT +1608
C406 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C407 nsp 00D 257 0512 903 CK73F1E104ZT +1608
C408-410 00D 254 4464 951 CE67C0J220MT(MV-B) +REF
C411,412 nsp 00D 257 0512 903 CK73F1E104ZT +1608
C413,414 nsp 00D 257 0502 942 CC73CH1H2R0CT +1608
C415-419 nsp 00D 257 0512 903 CK73F1E104ZT +1608
C420 00D 254 4464 951 CE67C0J220MT(MV-B) +REF
C421,422 nsp 00D 257 0512 903 CK73F1E104ZT +1608
C423 00D 254 4464 951 CE67C0J220MT(MV-B) +REF
C424-429 nsp 00D 257 0512 903 CK73F1E104ZT +1608
C430 00D 254 4603 958 CE67W1E101MT(P.CAP) +REF
C432-434 nsp 00D 257 0512 903 CK73F1E104ZT +1608
C436-438 nsp 00D 257 0512 903 CK73F1E104ZT +1608
C441 00D 254 4464 951 CE67C0J220MT(MV-B) +REF
