Denon DCD-1500AE - Recycle Parts for Mechanism Unit

85
DCD-1500AE
Details of Recycle parts for Mechanism unit
＊You have to remove the parts that marked “WEEE Mark ◆ " when the recycling processing. (Europe model only)
Ref. No.
WEEE
Mark
Part Name Material Q'ty
1 MAIN CHASSIS ASS'Y Complex 1
2 CLAMPER BRACKET Steel 1
3 GUIDE CLAMP BRACKET Steel 1
4 LOADING MOTOR ASS'Y Complex 1
5 LOADING GEAR POM 1
6 LOADING GEAR 2ND POM 1
7 LOADING GEAR 3RD POM 1
8 SUB CHASSIS-L PC+ABS 1
9 SUB CHASSIS-R PC+ABS 1
10 TRAY PC+ABS 1
11 SLIDE-CAM POM 1
12 TRAVERSE ARM PC 1
14 CLAMPER H POM 1
15 CLAMPER L POM 1
16 LOADING BELT Rubber 1
17
◆
SWITCH P.W.B. Complex 1
18 5P PH WIRE Complex 1
19 SWITCH ESE22MH21 Complex 1
20 SWITCH ESE22MH23 Complex 1
21 POLY.SLIT WASHER 2.6X6X0.25C POLY 3
22 WIRE CLAMPER POM 1
23 PRECISION SCREW 1.7X2.2 TYPE3 Steel 2
24 SCREW 2.6X6 CBTS(B)-Z Steel 6
25 PRECISION SCREW 2X3(S) TYPE3 Steel 1
26 SCREW 2X6 CBTS(P)-Z Steel 2
27A
◆
TRAVERSE MECHA (FEED) ASS'Y Complex 1
23 PRECISION SCREW 1.7X2.2 TYPE3 3
27 PU CHASSIS ASS'Y 1
28 SHAFT HOLDER L 1
29 SHAFT HOLDER R 1
30 SHAFT TILT BASE 1
31 SHAFT TILT PLATE 1
32 TILT SPRING 2
33 MAIN SHAFT 1
34 SUB SHAFT 1
35 PU RACK GEAR 1
37 PICK UP HOP-1200R 1
38 PU SPRING 1
39 SHAFT SPRING 1
40 RACK GEAR SPRING 1
42 T/T MOTOR ASS'Y 1
43 SCREW 2.6X6 CBTS(S)-Z 2
44 SCREW 2.6X4 CBTS(S)-Z 1
46 SCREW 2.6X15 CFTS(S)-Z 2
47 SCREW 3X4 BSS 2
48 SCREW 3X8 BSS (A) 1
55 PRECISION SCREW 1.7X5 TYPE3 1
23 PRECISION SCREW 1.7X2.2 TYPE3 2
36 FEED GEAR 2ND ASS'Y 1
41 FEED MOTOR ASS'Y 1
50 POLY.SLIT WASHER 2.1X4X0.25C 2
53 FEED GEAR 3RD 1
