Denon DCD-1500AE - PWB Parts List (Cont.); Other Parts Group (Power;Display;HP)

63
DCD-1500AE
OTHERS PARTS GROUP
AS001 nsp 00D 205 1034 007 M3 SCREW TERMINAL
CX023 nsp 00D 205 0581 056 2P VH CONNECTOR BASE
CX024 nsp 00D 205 0581 085 2P VH CONNECTOR BASE
CX026 nsp 00D 205 0581 001 2P VH CONNECTOR BASE
CX031 nsp 00D 205 0233 032 3P EH CONNECTOR BASE
CX041 nsp 00D 205 0343 045 4P CONN.BASE(KR-PH)
CX051 nsp 00D 205 0343 058 5P CONN.BASE(KR-PH)
CX052 nsp 00D 205 0321 054 5P CONNE.BASE (RED)
CX081 nsp 00D 205 0233 087 8P EH CON BASE
CX082 nsp 00D 205 0343 087 8P CONN.BASE(KR-PH)
CY024 nsp 00D 205 0581 085 2P VH CONNECTOR BASE
CY042 nsp 00D 205 0406 047 4P CON BASE(KR-PH)
CY052 nsp 00D 205 0395 051 5P CONN.BASE(RED)L
CY112 nsp 00D 205 1260 017 11P FFC BASE(9610SA)
! F801 00D 206 1092 026 FUSE 25RF 1.0A F002
! F802 00D 206 1092 000 FUSE 25RF 1.6A F002
FB801 nsp 00D 235 0130 903 CHIP EMIFIL(11A121) +1608
FL601 nsp 00D 393 8072 107 FL TUBE(15-BT-101GNK *
JK401 00D 204 8264 000 H/P JACK (AU)
L801 nsp 00D 235 0142 920 COIL LHL08TB100KT
L802 nsp 00D 235 0140 919 COIL LHL10TB470KT
L803 nsp 00D 239 8019 002 LINE FILTER COIL
S601-607 00D 212 5604 907 TACT SWITCH-TA(ALPS)
S901 00D 212 1030 009 POWER SWITCH (TV-5)
ST801 - STYLE PIN
ST803-805 - STYLE PIN
AS802 - RADIATOR
AS803 - RADIATOR
AS805 - RADIATOR
nsp 00D 461 0991 026 RUBBER SHEET FL601
nsp 00D GEN 8020 FUSE LABEL SUB ASSY F801
nsp 00D GEN 8020 -2 FUSE LABEL SUB ASSY F802 *
- 0.6 JUMPER WIRE
nsp 00D 471 3304 015 3X8 CBS-Z
Ref. No. nsp Part No. Part Name Remarks Q'ty New
