Denon DCD-F109 Owner's Manual

17
Making system connections
In addition to connection of the audio cables, also connect the
system cable.
Also, connect the DCD-F109’s power cord to the AC outlet on the
DRA-F109 (stereo receiver, sold separately).
NOTE
Be sure to plug the DRA-F109’s power cord into a wall power outlet.
To a wall power
outlet
DRA-F109
DCD-F109
System cable
(Included with the DCD-F109.)
System functions
Auto power on function
When CD or iPod/USB (CD) is
pressed, the power of the respective
devices turns on and the DRA-F109’s
source switches automatically.
Alarm function
Playback can be performed at a set time using the DRA-
F109’s alarm function.
•For details, see the owner’s manual of the DRA-F109 (stereo
receiver, sold separately).
Auto standby function
When you set the auto standby function to ON for either of DRA-F109
or DCD-F109, the auto standby function works on the entire F109
system.
For the auto standby function, see page16.
About system functions
NOTE
Do not connect any of the past models to this unit with a
system cable because they are incompatible.
Device supporting system
connections (sold separately)
DRA-F109 (STEREO RECEIVER)
With system functions, operations are controlled by the DRA-F109.
Be sure to connect the DRA-F109 using system connections.
What you can do with the system
functions
When system connections are made between the DCD-F109
and DRA-F109 (stereo receiver, sold separately), the operations
described below can be performed.
n The DCD-F109 can be operated using the remote
control unit included with the DRA-F109.
n Auto power on function
(vpage17 “System functions”)
n Alarm function
(vpage17 “System functions”)
n Auto standby function
(vpage17 “System functions”)
Preparations
Informations
Operations
CD

Denon DCD-F109 Specifications

General

Audio formats supported	MP3, WMA
CD-RW playback	Yes
CD changer	No
Device type	HiFi CD player
Product color	Black
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	264 mm
Width	250 mm
Height	82 mm
Weight	2800 g
