+6.5V is not outputted.
-6.5V is not outputted.
Is the fuse normal?
Is the fuse normal?
Check IC4 and the periphery circuit, and replace it if defective.
Check IC2 and the periphery circuit, and replace it if defective.
Refer to FLOW CHART NO.2 <The fuse blows out.>.
Refer to FLOW CHART NO.2 <The fuse blows out.>.
NO
NO
YES
YES
FLOW CHART NO.6 (405-MC2-3059 : I/O UNIT)
FLOW CHART NO.7 (405-MC2-3059 : I/O UNIT)
To Next Page
