35
The key operation is not functioning.
Are the contact point and the installation state of the key
switches (SW400 - SW448) and rotary encoder (SW449 -
SW451) nomal?
Does LED (D460 - D498) light correctly?
Replace IC400.
Re-install the switches correctly or replace the poor switch.
Check the Q400 - Q405, Q410 - Q417 and their periphery,
and replace it if defective.
Check key switches (SW400 - SW448), rotary
encoder (SW449 - SW451) and their periphery,
and replace it if defective.
NO
NO
NO
YES
YES
YES
FLOW CHART NO.8 (405-MC2-3058 : CONTROL UNIT)
When pressing each key switches, turning rotary switches and turning rotary
encoder, does the voltage of each pin of IC400 (shown below) decrease?
Key switches
SW400, SW406, SW412, SW418, SW424, SW430 : IC400 55pin
SW401, SW407, SW413, SW419, SW425, SW431 : IC400 56pin
SW402, SW408, SW414, SW420, SW426, SW432 : IC400 57pin
SW403, SW409, SW410, SW421, SW427, SW433 : IC400 58pin
SW404, SW410, SW411, SW422, SW428, SW434 : IC400 59pin
SW405, SW411, SW412, SW423, SW429, SW435 : IC400 66pin
SW437, SW438, SW441, SW444, SW446, SW448 : IC400 67pin
SW436, SW439, SW440, SW442, SW445, SW447 : IC400 70pin
SW443 : IC400 71pin
Rotary encoder
SW449, SW450, SW451 : IC400 71pin
To Next Page
