Denon RCD-M39 Service Manual

MCU&CD
MCU&CD PCB ASS'
Y
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model EK : U.K. model E1C : China model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC11 943243101160D I.C, U-COM RCD-M39 (TMPM330FYFG, TOSHIBA) CVIANAM1684CR *
IC12 943246100770D I.C , EEPROM (16KBIT,SOP-8P,K-Line) CVIK24C16BSIRGA
IC13 943234009290S I.C , RESET 2.4V (200ms,C-MOS,SOT23-5P) CVIS80124CLMCJIJT2
IC21 943245006980S I.C , CD DSP (SERVO,AMPLIFIER,DSP,LQFP-80P) CVITC94A92FG
IC22 943231101210D I.C , REGULATOR(SOT-223) CVIKIA1117BS33
IC23 943231101240D I.C , REGULATOR(SOT-223) CVIKIA1117BS15
IC31 943239006900S I.C , 5-CH MOTOR DRIVE(REG,SSOP-28P) CVIIP4001CRLTF_CN
IC41 943243101170D I.C, USB DECODER FLASH RCD-M39 (TMP92FD28FG) CVIANAM1685CR *
IC42 23671011050AS I.C,IPODAUTHENTICATIONFROMD&M CVI23671011050AS_DM
IC43 943239100710S I.C,CURRENTLIMITE(1.5A,UDFN-6P) CVINCP380HMU15AATBG
D101-106 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D107 90M-HD201820R DIODE, SCHOTTKEY BARRIER HVDRB160L60TE25
D108 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D109,110 90M-HD201820R DIODE, SCHOTTKEY BARRIER HVDRB160L60TE25
D201-203 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D401 90M-HD201820R DIODE, SCHOTTKEY BARRIER HVDRB160L60TE25
Q102-105 943215500020S T.R , RT1P141C(10K-10K) CVTRT1P141C
Q106 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q107 943215500020S T.R , RT1P141C(10K-10K) CVTRT1P141C
Q108 943215500140D T.R , RT1P144C(10K-47K) CVTRT1P144C
Q109 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q201 00D9430058908 T.R , CHIP , SOT-23 HVTKTA1504SYRTK
Q401,402 943215500020S T.R , RT1P141C(10K-10K) CVTRT1P141C
Q403 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q404 943215500020S T.R , RT1P141C(10K-10K) CVTRT1P141C
Q405-410 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
CAPACITORS GROUP
C101-105 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C106 nsp CAP, CHIP(1608, 50V/15pF) CCUS1H150JA
C107 nsp CAP,CHIP(1608,50V/12pF) CCUS1H120JA
C108 nsp CAP , CHIP ELECT HCEC0JRV102T
C109,110 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C111 nsp CAP, CHIP(1608, 50V/15pF) CCUS1H150JA
C112 nsp CAP,CHIP(1608,50V/22pF) CCUS1H220JA
C114 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C116 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C117 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C118 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA
C119,120 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C121 nsp CAP, CHIP(1608, 10V/1uF) CCUS1A105KC
C122 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C123 nsp CAP, CHIP ELECT(35V/10uF) HCEC1VRV2100T
C124 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C126 943134500030S CAP, SMD ELECT(16V/470uF) CCEC1CRV471T
C130 nsp CAP,CHIP(1608,50V/470pF) CCUS1H471JA
C132 nsp CAP,CHIP(1608,50V/220pF) CCUS1H221JA
C201 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C202 nsp CAP,CHIP(1608,50V/2200pF) CCUS1H222KC
C203 nsp CHIP ELECT CAP HCEC0JRV2101T
C204 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C205 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C206 nsp CAP,CHIP(1608,50V/4700pF) CCUS1H472KC
C207 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C208 nsp CHIP CAP 0.015UF 50V CCUS1H153KC
C209 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C211 943134500030S CAP, SMD ELECT(16V/470uF) CCEC1CRV471T
C212 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C213 nsp CAP, CHIP(1608, 50V/0.033uF) CCUS1H333KC
C214 nsp CHIP CERAMIC CAP (1608, 5600p) CCUS1H562KC
C215 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C216,217 nsp CAP,CHIP(1608,50V/470pF) CCUS1H471JA
C218 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C220,221 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C222 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C223 nsp CAP , CHIP ELECT HCEC0JRV2470T
C224,225 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C226 nsp CAP , CHIP ELECT HCEC0JRV2470T
C227 nsp CAP,CHIP(1608,50V/18pF) CCUS1H180JA
C228 nsp CAP, CHIP(1608, 50V/15pF) CCUS1H150JA
C229,230 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C231 nsp CHIP ELECT CAP HCEC0JRV2101T
C232-234 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C235 nsp CHIP CAP 0.015UF 50V CCUS1H153KC
C236 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C237 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C238 nsp CAP , CHIP ELECT HCEC0JRV2470T
C239 nsp CHIP CAP 47PF 50V CCUS1H470JA
C240,241 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C242 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC
C243 nsp CHIP ELECT CAP HCEC0JRV2101T
C244,245 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C246 nsp CAP, CHIP ELECT(35V/10uF) HCEC1VRV2100T
C248 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C249 943134500030S CAP, SMD ELECT(16V/470uF) CCEC1CRV471T
C250,251 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C252 943134500030S CAP, SMD ELECT(16V/470uF) CCEC1CRV471T
C253 nsp CHIP ELECT CAP HCEC0JRV2101T
C254 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C255-257 nsp CAP,CHIP(1608,50V/22pF) CCUS1H220JA
C303-305 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C307 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C308,309 943134500030S CAP, SMD ELECT(16V/470uF) CCEC1CRV471T
C310 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C311 nsp CHIP ELECT CAP HCEC0JRV2101T
C312 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C324,325 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C401,402 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C403 nsp CAP, CHIP ELECT(16V/10uF) HCEC1CRV2100T
C404,405 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C406 nsp CAP, CHIP ELECT(16V/10uF) HCEC1CRV2100T
C407,408 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
6
