Denon RCD-M39 Service Manual

MCU&CD
REF No. Part No. Part Name Remarks Q'ty New Ver
C409 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC
C410,411 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C412 nsp CAP, CHIP(1608, 50V/20pF) CCUS1H200JA
C413 nsp CAP,CHIP(1608,50V/18pF) CCUS1H180JA
C414,415 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C417 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C418 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C420-422 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C433 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C901-911 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C912,913 nsp CAP,CHIP(1608,50V/22pF) CCUS1H220JA
OTHERS PARTS GROUP
L106 nsp FERRITE,CHIPBEAD(60ohm,2012) CLZ9R001Z
L201 90M-LU000220R INDUCTOR CHIP 10UH (3225 PKG) HLQ10E100KRZ
L204 nsp FERRITE,CHIPBEAD(60ohm,2012) CLZ9R001Z
L401 nsp FERRITE,CHIPBEAD(60ohm,2012) CLZ9R001Z
RN11 nsp CHIP RES(10KOHM 5% 1608X4) CRJ104DJ103T
X101 943141100750D X-TAL, 10MHz, HC-49/SMD, 12pF COX10000E120S
X201 943141001190S SMD CRYSTAL (16.9344MHZ, HC-49/SMD, 12PF) COX16934E120S
X401 943141001200S CRYSTAL , SMD(9MHZ, HC-49/SMD, 5PF) COX09000E150S
CWM2 nsp WAFER,SMD(2MMPITCH) CJP06GA208ZY
CWM3 nsp WAFER,SMD(2MMPITCH) CJP05GA208ZY
CWMD CJP07GA208ZY
CWMF nsp WAFER,SMD(2MMPITCH) CJP05GA208ZY
FCM1 nsp WAFER , CARD CABLE SMD CJP16GA193ZY
FCMA CJP19GA193ZY
FCMC nsp WAFER CJP21GA193ZY
