Denon RCD-M39 Service Manual

EXPLODED
EXPLODED
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model EK : U.K. model E1C : China model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
P1 nsp Power & AMP PCB ASS'Y CUP12446Z 1
P1a - FRONT PCB -
P1b - CONNETER PCB -
P1c - AMP PCB -
P1d - CONNETER PCB -
P1e - POWER PCB -
P1f - SPEAKER PCB -
P2 nsp Digital Input PCB ASS'Y CUP12447Z 1
P2a - DIGITAL INPUT PCB -
P2b - DC-DC PCB -
P2c - REGULATOR PCB -
P2d - DAB PCB -
P3 nsp MCU & CD PCB ASS'Y CUP12448Z 1
P4 943183100210S TUNER , RDS , FM(PAL TYPE) , SI4705- B20 E2 CNVMW104FV1-S6
3
1
P4 943183100200S TUNER,FM(SCREW:FTYPE),SI4704-B20 E3 CNVMW004FV1-S6
3
1
P5 943189100220S DAB MODULE EK CNVGYRO1138Z03 1 *
! P6 943101000290D TRANS E2,EK CLT5P047ZE 1
! P6 943101000990D TRANS E3 CLT5P047ZU 1
! P6 943101101960S TRANS E1C CLT5P047ZH 1 * Ver.7
P7 943641500240D INLET E2,EK CJJ8A019Z 1 *
P7 943641500250D INLET E3 CJJ8A020Z 1 *
P8 943302100130D CD MECHANISM ASS'Y (KOTY LOADER) CJDKT690 1
1 943412009010D VOLUME KNOB ASSY SP CGK1A162YA 1 Ver.8
1 943412009020D VOLUME KNOB ASSY BK CGK1A162ZA 1 Ver.8
2 - INNER PANEL ASSY SP -
2 - INNER PANEL ASSY BK -
2-1' nsp INNER PANEL SP GW1A522RGG45 1 *
2-1' nsp INNER PANEL BK CGW1A522B28 1 *
2-2' nsp CAP SP CGR1A511C73 1
2-2' nsp CAP BK CGR1A511 1
2-3' nsp TAPE,POWER CAP CHP1A077 1
3 943415100390D DOOR SP CGR1A537RGG45 1 *
3 943415100400D DOOR BK CGR1A537B28 1 *
4 943416100780D FL WINDOW CGU1A464Z 1 *
5 42141002301AD BADGE , DENON SP CGB1A254Y 1 Ver.6
5 42141002300AD BADGE , DENON BK CGB1A254Z 1 * Ver.6
6 943402102710D FRONT PANEL SPE2 CKM1A246ZC62 1 *
6 943402102720D FRONT PANEL BKE2 CKM1A246ZC45 1 *
6 943402102730D FRONT PANEL BKE3, CKM1A246YC4
5
1*
6 943402103350D FRONT PANEL
JP
BKE1C
CKM1A246XC45 1 * Ver.7
6 943402102740D FRONT PANEL SP CKM1A246XC62 1 *
6 943402102790D FRONT PANEL SPEK CKM1A246WC62 1 *
6 943402102800D FRONT PANEL BKEK CKM1A246WC45 1 *
7 00D9430189903 LENS CGL1A254 1
10 943411102000D KNOB,BUTTON SP CBT1A1166C81 1 * Ver.2
10 943411102010D KNOB,BUTTON BK CBT1A1166C57 1 *
11 nsp USB EARTH PLATE CMC1A351 4
12 nsp EARTH PLATE CMC1A350 1
13 nsp MECHA SUPPORT CMH1A331 2
14 00D9430094603 CUSHION CHG1A285 4
15 00D9430094506 FOOT CKL1A189 4
16 nsp BOTTOM CHASSIS CUA1A336 1
17 943401100720D TOP CABINET SP CKC3A186D11 1 *
17 943401100730D TOP CABINET BK CKC3A186K117 1 *
18 nsp HEAT SINK CMY1A382 1
20 nsp INSULATOR CMX1A310 1
21 943406101180D REAR PANEL E2 CKF1A458Z 1 *
21 943406101190D REAR PANEL E3 CKF1A458Y 1 *
21 943406101200D REAR PANEL SP CKF3A458Z 1 *
21 943406101210D REAR PANEL EK CKF2A458Z 1 *
21 943406101320D REAR PANEL E1C CKF1A458X 1 * Ver.7
22 nsp WASHER EK CNW2A028 1 Ver.7
23 nsp DAB NUT EK CNE1A009 1 Ver.7
24 nsp PCB BRACKET CMD1A629 1
25 nsp BRACKET , PCB CMD1A387 2
26 nsp BRACKET , PCB CMD1A569 9
27 nsp FLT BRACKET CMD1A468 2
28 nsp CUSHION , MECHA CHG1A546 1
29 943533007120M CUSHION EK CHG1A236 2 Ver.5
30 nsp CUSHION , TRANS(BLACK) EK CHG1A144Z 1
31 943453100360S CLAMPER CHR1A305(DAB) 1 * Ver.5
SCREWS
S1 nsp SCREW 4X8 CTB4+8FR 4
S2 nsp SCREW CTW3+18JR 2
S3 nsp SCREW(CTB3+8JFZR) CTB3+8JFZR 5
S4 nsp CTBD3+6FFZR CTB3+10JFZR 15
S5 nsp SCREW
CTBD3+8JFZR
CTBD3+8JFN
6
S6 nsp SCREW
CTWD4+6FFZR
CTWD4+6FFN
2
S7 nsp SCREW CTB3+6FFZR 11
S7 nsp SCREW EK CTB3+6FFZR 9
S8 nsp SCREW CTS3+8JFZR 2
S9 nsp SCREW CTB3+6JFZR 14
★FCMA ns
p
CABLE , CARD
(
19P, 80mm, 1mm PITCH
)
CWC4F4A19A080B
0
1
★FCMC ns
p
CARD CABLE
(
21P,1.0mm,250mm,B TYPE
)
CWC4F4A21A200B
0
1
★CW09 ns
p
WIRE ASS'Y
(
3P, 120mm, Flat T
yp
e
)
CWB2B90312047 1
★CWAK ns
p
WIRE ASS'Y
(
7P, 120mm, Flat T
yp
e
)
CWB2B90712047 1
★CBAD ns
p
WIRE ASS'Y
(
7P, 80mm, Flat T
yp
e
)
CWB2B907080G7 1
★CBAL ns
p
WIRE ASS'Y
(
7P, 120mm, Flat T
yp
e, Shield
)
CWB2B9071204700
1
1
★CBFF ns
p
WIRE ASS'Y
(
5P, 150mm, Flat T
yp
e
)
CWB1C905150G7 1
★CBFJ ns
p
WIRE ASS'Y
(
7P, 100mm, Flat T
yp
e
)
CWB2B90710047 1
★CBOM ns
p
WIRE ASS'Y CWB1C911100BM 1
★CBIB ns
p
WIRE ASS'Y
(
7P, 80mm, Flat T
yp
e
)
CWB2B00708047 1
★CBRQ ns
p
WIRE ASS'Y
(
5P, 120mm, Flat T
yp
e
)
CWB2B90512047 1
★CBS8 ns
p
WIRE ASS'Y CWB1A903120EN 1
8
