Denon RCD-M39 Service Manual

POWER & AMP
POWER & AMP PCB ASS'Y
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model EK : U.K. model E1C : China model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC71 943239100850D I.C, HYBRID AMP (2-channel class AB) CVISTK433-060N *
IC72 00MHC10200090 I.C , HEADPHONE (JRC) HVINJM4556AL
IC91 943239010400S I.C, REGULATOR(3.3V/TO-252) CVINJM2845DL133
IC92 00D9430183909 REGULATOR IC HVIKIA7912PI
D701 90M-HD201820R DIODE, SCHOTTKEY BARRIER HVDRB160L60TE25
D706 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D708,709 00MHD20015210 DIODE HVD1SS133MT
D710,711 00D9430182502 DIODE , RECT 1N4003 CVD1N4003T
D712 90M-HE200390R DIODE , BRIDGE(10A/600V) HVDGBJ1006
D713,714 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D801 00D9430106203 LED SPR39MVW3 2COLOR HVDSPR39MVW3
D806-815 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D901 90M-HD302280R DIODE , ZENER (CHIP,6.8V) HVDUDZS6.8BSR
D902 00D9430209400 DIODE , RECT 1N4003 CVD1N4003SRT
D903,904 00MHD20059100 DIODE , SCHOTTKY HVD21DQ10T
D905-910 00D9430209400 DIODE , RECT 1N4003 CVD1N4003SRT
D911,912 00D9430087102 ZENER DIODE MTZJ20B 1/2W HVDMTZJ20BT
D913,914 00D9430209400 DIODE , RECT 1N4003 CVD1N4003SRT
D915,916 90M-HD201820R DIODE, SCHOTTKEY BARRIER HVDRB160L60TE25
D917 00D9430209400 DIODE , RECT 1N4003 CVD1N4003SRT
D919 00D9430209400 DIODE , RECT 1N4003 CVD1N4003SRT
D922,923 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D925 943202500460D DIODE , ZENER(CHIP,15V) E3 HVDUDZS15BSR
D928-938 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D939 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
D940,941 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D942 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T E3 HVD1SS355T
D943 90M-HD302270R DIODE , ZENER (CHIP,5.6V) HVDUDZS5.6BSR
D945 00D9430209400 DIODE , RECT 1N4003 CVD1N4003SRT
D946,947 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
Q701 943215500140D T.R , RT1P144C(10K-47K) CVTRT1P144C
Q702 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q703 943215500140D T.R , RT1P144C(10K-47K) CVTRT1P144C
Q704,705 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551
Q706-709 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B
Q710 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C
Q711 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q712 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C
Q713 943215500020S T.R , RT1P141C(10K-10K) CVTRT1P141C
Q714 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401
Q716 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401
Q717 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551
Q718 943215500020S T.R , RT1P141C(10K-10K) CVTRT1P141C
Q720 943215500140D T.R , RT1P144C(10K-47K) CVTRT1P144C
Q806 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q901 943219006820S TR KTC1027Y CVTKTC1027YT
Q902 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C
Q903 963216500060S T.R,RT1N144C(10K-47K) E3 CVTRT1N144C
Q906-908 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q909 943219006820S TR KTC1027Y CVTKTC1027YT
Q910 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q911 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C
Q912 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551
Q913 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
RESISTORS GROUP
R702,703 nsp RES,M-OXIDEFILM(1W/100ohm) CRG1SANJ101RT
R704,705 943124500040S RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT
R706,707 943121006200M RES. CRD25FJ4R7T
R708,709 nsp RES , CEMENT CRF5EKR22
R710,711 nsp RES, CARBON(1/4W,2.7Kohm,J) CRD25TJ272T
CAPACITORS GROUP
C156 943134502030D CAP, ELECT(50V/10uF) CCEA1HH100TC
C701,702 943134502030D CAP, ELECT(50V/10uF) CCEA1HH100TC
C704,705 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C708,709 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT
C710 nsp CAP, ELECT(10V/470uF) CCEA1AH471TC
C711,712 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C713 nsp CAP, ELECT(25V/47uF) CCEA1EH470TC
C716,717 nsp CAP , ELECT (50V/47uF) CCEA1HH470TC
C718,719 nsp CAP, CERAMIC(50V/470pF/K) CCKT1H471KB
C720 00MOA47702520 CAP , ELECT CCEA1EH471T
C723,724 nsp CAP, CERAMIC(50V/100pF/K)
CCKT1H101KB
C726 943134010580S ELECT CAP 220UF 35V CCEA1VH221T
C727 00D2544693942 CAP, ELECT(50V/220uF,ELNA/RFO) CCEA1HRFO221E
C728 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC
C729,730 nsp CERAMIC CAP 5pF 50V CC CCCT1H050CC
C734 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C735,736 nsp CAP , POLYPROPYLENE(SEORYONG, CCMP2A102JR16T
C737,738 00MOF15104040 CAP,METAL-FILM(100V/0.1uF) CCME2A104JXT
C739,740 943139001280S METALLIZED FILM CAP CCME2A103JXT
C741 90M-OF100490R CAP, METAL PE FILM(250V/0.1uF) KCME2E104JP04T
C742,743 943134502110D CAP , ELECT(TOSHIN, UTSP, 35V/4700uF, 85'C) CCEA1VUTSP472E *
C744,745 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C747 00MOA47702520 CAP , ELECT CCEA1EH471T
C750 943134010580S ELECT CAP 220UF 35V CCEA1VH221T
C752-756 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C758 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC
C759,760 943134502030D CAP, ELECT(50V/10uF) CCEA1HH100TC
C761 00D2544693942 CAP, ELECT(50V/220uF,ELNA/RFO) CCEA1HRFO221E
C763,764 943134010580S ELECT CAP 220UF 35V CCEA1VH221T
C765-768 nsp METALLIZED FLIM CAP (100V/0.22UF) CCME2A224JXT
C769,770 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA
C771,772 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C776,777 943134502030D CAP, ELECT(50V/10uF) CCEA1HH100TC
C780,781 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C784,785 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA
C791 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C792 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C801 943134502040D CAP , CERAMIC CCEA1CKS101TC
1
