Denon RCD-M39 Service Manual

POWER & AMP
REF No. Part No. Part Name Remarks Q'ty New Ver
C802 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C803 nsp CHIP CAP 47PF 50V CCUS1H470JA
C804 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C805-807 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA
C808-810 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C811-813 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C815,816 nsp CAP,CHIP(1608,50V/4700pF) CCUS1H472KC
C819-821 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C822 943134501930D CAP, ELECT(50V/10uF)-S CCEA1HKS100TC
C824,825 943139001280S METALLIZED FILM CAP CCME2A103JXT
C827-829 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C832 943134501950D CAP, ELECT(50V/1uF)-S CCEA1HKS1R0TC
C835 943134502040D CAP , CERAMIC CCEA1CKS101TC
C836 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C837,838 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C901 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT
C902,903 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C904 943134502120D CAP, ELECT(TOSHIN, UTSP, 25V/2200uF), 85'C) CCEA1EUTSP222E *
C905 943134502130D CAP, ELECT(TOSHIN, UTSP, 25V/1000uF, 85'C) CCEA1EUTSP102E *
C906,907 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C908,909 943134502140D CAP, ELECT(TOSHIN, UTSP, 16V/220uF), 85'C) CCEA1CUTSP221T *
C910 943134502030D CAP, ELECT(50V/10uF) CCEA1HH100TC
C911 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C912 943134502030D CAP, ELECT(50V/10uF) CCEA1HH100TC
C913 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C914 943134502030D CAP, ELECT(50V/10uF) CCEA1HH100TC
C915 943134502070D CAP, ELECT(50V/220uF) CCEA1HH221EC
C916,917 943134502100D CAP , ELECT(63V/100uF) CCEA1JH101EC
C918 943134502030D CAP, ELECT(50V/10uF) CCEA1HH100TC
C919 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C920 943134502030D CAP, ELECT(50V/10uF) CCEA1HH100TC
C922 00D9430024408 CAP , CERAMIC(X1/Y2/SC) 0.0047uF 2.5KV KCKDKS472ME
C925,926 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C927 943134502010D CAP, ELECT(50V/0.68uF) CCEA1HHR68TC
C928 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C929 nsp CAP, ELECT(16V/2200uF) CCEA1CH222EC
C930 943134502030D CAP, ELECT(50V/10uF) E3 CCEA1HH100TC
C934 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C935 943134502120D CAP, ELECT(TOSHIN, UTSP, 25V/2200uF), 85'C) CCEA1EUTSP222E *
C938 nsp CAP, ELECT(50V/4.7uF) CCEA1HH4R7TC
C939 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C944,945 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C947 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C951 00D2544693939 CAP , ELEC ELNA RFO SERIES 100uF/50V CCEA1HRFO101T
C952 nsp CAP, CHIP(1608, 10V/1uF) CCUS1A105KC
C953 nsp CAP, CHIP(2012, 6.3V/10uF, X5R) CCUC0J106KC
C954,955 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C956 nsp CAP, ELECT(50V/4.7uF) CCEA1HH4R7TC
C957 nsp CAP, ELECT(6.3V/1000uF) CCEA0JH102TC
C958 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C959 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C991-995 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C996 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C997 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C998 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
OTHERS PARTS GROUP
BK11 nsp BRACKET , PCB CMD1A569
BK71 nsp BRACKET , PCB CMD1A569
BK72 nsp BRACKET , PCB CMD1A387
BK73 nsp BRACKET , PCB CMD1A569
BK74 nsp BRACKET , PCB CMD1A387
BK75,76 nsp BRACKET , PCB CMD1A569
BK81,82 nsp FLT BRACKET CMD1A468
BK91-93 nsp BRACKET , PCB CMD1A569
! CN91 943641500240D INLET , AC , NON-POL (250V/2.5A PCB MOUNT TYPE) E2, EK CJJ8A019Z *
! CN91 943641500250D INLET , AC , POL (125V/7A PCB MOUNT TYPE) E3 CJJ8A020Z *
CN98,99 nsp WAFER,FFC(5P-1mm,ANGLE) CJP07GB113ZY
! F901 nsp HOLDER , FUSE KJCFC5S
! F901 943652001740S FUSE E2, EK KBA2C1000TLEY
! F901 00D9430212600 FUSE , GLASS TUBE(125V, 2A, 20MM) E3 KBA1C2000A4UY 11
FL81 943172007420D V.F.D (FUTABA, 16ST103GINK) CFL16ST103GINK Ver.3
GND3,4 nsp PALTE , EARTH HJT1A025
J701-705 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J707,708 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J710 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J712-714 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J719 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J721-729 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J731-736 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J739 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J741-743 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J745,746 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J749 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J751-753 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J755,756 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J765 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J803-807 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J810 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J813 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J815 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J817-847 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J849-853 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J860 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J901-906 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J908-910 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J912-915 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J917-919 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J921-927 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J929-932 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J934-941 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J950-954 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J956-958 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J960-965 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
J967-977 00D9430101101 WIRE,COPPER SN95/PB5, 0.6 C3A206
JK71 90M-YT003280R TERMINAL CJJ5P011Z
