94
PowerScout HD
Appendix F
Specification Description
Communication
Hardware RS-485, Ethernet, and USB
Supported Protocols Modbus RTU or BACnet Master Slave Token Passing protocol (MS/TP)
Modbus (using SunSpec IEEE-754 single precision floating point model)
Max Communication Length 1200 meters with Data Range of 100K bits/second or less
RS-485 Loading 1/8 unit
Communication Rate (baud) Modbus: 9600 (Default), 19200, 38400, 57600, 76800, 115200
BACnet: 9600, 19200, 38400, 76800
Data Bits 8
Parity None, Even, Odd
Stop Bit 2, 1
Termination None provided
Data Formats Modbus RTU, BACnet MS/TP, Modbus TCP or BACnet IP
Mechanical
Wire Connections 12-28 AWG 600 VAC, Voltage connection must be #14 AWG or larger & 600 VAC rated
Mounting Enclosure or Panel Mount
High Voltage Cover IP30. Included with all models except PS12HD-P-D-N
Operating Temperature
-20 to + 60⁰ C (-4 to 140⁰ F) (the colder the temperature the more voltage needed to
power the board)
Humidity 5% to 95% non-condensing
Enclosure ABS Plastic, 94-V0 flammability rating
Conduit Connections: 1” (PS12HD/PS48HD Wall Mount enclosures)
or ½” (PS3HD Wall Mount enclosure)
PS24HD/PS48HD Dimensions (L) 33.7cm x (W) 25.1cm x (H) 8.0 cm (13.3” x 9.8” x 3.1”) (enclosure version)
(L) 26.2cm x (W) 24.1cm x (H) 8.0 cm (10.3” x 9.5” x 3.1”) (mounting plate version)
PS12HD Dimensions (L) 24.8cm x (W) 25.1cm x (H) 8.0 cm (9.8” x 9.8” x 3.1”) (enclosure version)
(L) 17.8cm x (W) 26.3cm x (H) 8.0 cm (7.0” x 10.4” x 3.1”) (mounting plate version)
PS3HD Dimensions (L) 19.1cm x (W) 8.2cm x (H) 3.8cm (7.5” x 3.2” x 1.5”) (DIN Rail Version)
(L) 25.7cm x (W) 14.0cm x (H) 5.4cm (10.1” x 5.5” x 2.1”) (Wall Mount Version)
ViewPoint™ HD Minimum System Requirements
Operating System Windows® 7, Windows® 8, Windows® 10
Communications Port USB or Ethernet connection
