DentalEZ aXcs Series - Page 31

3-11/16"
15-1/8" ± 1/32"
5-11/16"
Suggested
Electrical Outlet
Location
AIR
VACUUM
WATER
DRAIN
2"
2-1/8"
8-5/8"
± 1/32"
5-1/8"
4-3/4"
1/2"
1-1/8"
7-9/16"
Chair Center Line
USC Base
Horizontal
Center Line
Ø 7/8" through
3 x Ø 5/8" through
USC Base
4 x For #10-32
Anchors
Chair Side
USC TEMPLATE (aXcs

CMU)
18-3/4"
13"
P.N. 2677-052 April, 1999
