Desoutter CVIR II Manual

Desoutter - ZAC de la Lorie - 38 rue Bobby Sands
BP 10273 - 44818 Saint-Herblain Cedex - France
Part no
Issue no
Language
Date
Page
6159932730
06
English
10/2015
10/36
10/36
2.4. CVIx II - Tightening Results
CVIxII Memory Address
Data
Description
Access
(R/W)
Size
(bytes)
Value
Type
In Bytes
In Words
Hexa. Deci. Hexa. Deci.
CVIxII - Data Outputs => PLC Inputs
--- --- --- --- --- --- --- ---
0x0002 0002 0x0001 0001
Final Torque Result R 4 Float
0x0006 0006 0x0003 0003
Torque Trend R 2 Integer
0x0008 0008 0x0004 0004
Final Angle Result R 4 Float
0x
000C
0012
0x
0006
0006
Angle Trend R 2 Integer
--- --- --- --- --- --- --- ---
Final Torque Result: this is the IEEE float value of the torque displayed on the controller.
Torque Trend: indicates wether the torque is :
0x00 No report
0x01 Torque is below the lower limit
0x02 Torque is over the upper limit
0x03 Torque is in the limits
Final Angle Results: this is the IEEE float value of the angle displayed on the controller.
Angle trend: indicates wether the angle is :
0x00 No report
0x01 Angle is below the lower limit
0x02 Angle is over the upper limit
0x03 Angle is in the limits
