Desoutter - ZAC de la Lorie - 38 rue Bobby Sands
BP 10273 - 44818 Saint-Herblain Cedex - France
Part no
Issue no
Language
Date
Page
6159932730
06
English
10/2015
8/36
8/36
External Stop: When the external stop option is set in a cycle rundown speed, final speed or run reverse
phase, the controller will stops the current phase and shifts to the next one as soon as the
signal shifts to “1”.
2.2.3. Outputs Descriptions
Cycle Echo 1/2/4/8: Binary coded 1-2-4-8 selected cycle echo. The cycle echo is sent back only if it corresponds
to a programmed cycle in the station. Otherwise it is at “0”.
Accept Report: Active when the cycle is over and the tightening cycle report is OK.
Reject Report: Active when the cycle is over and the tightening cycle report is NOK.
Number of cycles OK: This signal switches to “1” when the number of cycles run with an Accept Report is equal to
the programmed number of cycles OK in the selected cycle parameters.
In Cycle: Response to the Start Cycle request. Drops to “0” at the end of a tightening or untightening.
Ready: This signal is at “1” when the controller is in working order.
Run reverse enabled: A spindle Reverse validation has been activated.
Synchro OUT: Used in conjunction with Synchro IN input to synchronise the tightening cycle phases of
several controllers (synchro waiting phase).
For detailed information, please read the CVIC II / CVIL II / CVIR II controller manual.
