Det-Tronics X3302 - Page 30

28 95-87682.1
Medium Sensitivity
Fuel
Size/
Flow Rate
Distance
feet (m)
Horizontal
(degrees)
Horiz. Average
Response Time
(seconds)**
Vertical
(degrees)
Vert. Average
Response Time
(seconds)**
Hydrogen
30 inch plume/
100 SLPM*
50 (15.2)
+45
-45
2.6
2.0
+45
-30
2.5
2.2
Methanol 1 x 1 foot 35 (10.7)
+45
-45
4.3
6.0
+45
-30
3.3
4.4
Syngas***
30 inch plume/
120 SLPM*
50 (15.2)
+45
-45
3.6
3.3
+45
-30
6.0
3.9
Methane
30 inch plume/
40 SLPM*
30 (9.1)
+45
-45
3.1
3.4
+45
-30
3.6
2.4
* Standard Liters Per Minute (Standard conditions defined as +25°C and 14.696 PSIA).
** Add 2 seconds for EQP model.
***Syngas composition: 53% H2, 24% CH4, 11% N2, 8% CO, 4% CO2.
FM Approval and Performance Report – Continued
Low Sensitivity
Fuel
Size/
Flow Rate
Distance
feet (m)
Horizontal
(degrees)
Horiz. Average
Response
Time
(seconds)**
Vertical
(degrees)
Vert. Average
Response Time
(seconds)**
Hydrogen
30 inch plume/
100 SLPM*
25 (7.6)
+45
-45
5.4
5.3
+45
-30
6.4
4.7
Methanol 1 x 1 foot 17.5 (5.3)
+45
-45
7.6
7.5
+45
-30
7.0
4.9
Syngas ***
30 inch plume/
120 SLPM*
25 (7.6)
+45
-45
7.1
5.6
+45
-30
6.9
6.1
Methane
30 inch plume/
40 SLPM*
15 (4.6)
+45
-45
7.2
6.0
+45
-30
6.9
4.9
* Standard Liters Per Minute (Standard conditions defined as +25°C and 14.696 PSIA).
** Add 2 seconds for EQP model.
***Syngas composition: 53% H2, 24% CH4, 11% N2, 8% CO, 4% CO2.
Medium Sensitivity – Sustained Fire Mode
Fuel
Size/
Flow Rate
Distance
feet (m)
Horizontal
(degrees)
Horiz. Average
Response Time
(seconds)**
Vertical
(degrees)
Vert. Average
Response Time
(seconds)**
Hydrogen
30 inch plume/
100 SLPM*
50 (15.2)
+45
-45
8.1
7.8
+45
-30
9.9
8.3
* Standard Liters Per Minute (Standard conditions defined as +25°C and 14.696 PSIA).
** Add 2 seconds for EQP model.
Low Sensitivity – Sustained Fire Mode
Fuel
Size/
Flow Rate
Distance
feet (m)
Horizontal
(degrees)
Horiz. Average
Response Time
(seconds)**
Vertical
(degrees)
Vert. Average
Response Time
(seconds)**
Hydrogen
30 inch plume/
100 SLPM*
25 (7.6)
+45
-45
7.2
8.8
+45
-30
7.6
8.4
* Standard Liters Per Minute (Standard conditions defined as +25°C and 14.696 PSIA).
** Add 2 seconds for EQP model.
