Detecto DL Series

8529-0637-2M Rev A  DL Series Operation Manual
6
PRINTER, CONT.
Gap Paper Mounts Recycle
Pull out spring
Step 7 - Gap paper mounts recycle
Install Plain Paper
Different from the way in installing gap paper shown. U-shaped paper retaining spring is not
needed anymore. All you need to do is to put the paper into the paper sensor and let the tear
part be outside.
