Job card overview
TCD 2013 2VSorted numerically
W 09-02-02 Removing and installing the gearcase cover Gearcase
W 10-02-01 Removing and installing the camshaft Camshaft
W 10-02-02 Checking the camshaft Camshaft
W 11-01-01
Setting valve clearance (with exhaust return module
installed)
Control parts
W 11-01-01
Setting valve clearance (with or without removal of
exhaust return module)
Control parts
W 11-02-01
Removing and installing the rocker arm and rocker
arm bracket
Control parts
W 11-02-02
Disassembling, assembling and checking the rocker
arm and rocker arm
bracket
Control parts
W 15-02-01 Removing and installing the lubricating oil cooler Lubricating oil cooler
W 15-02-02
Removing and installing the lubricating oil cooler
housing
Lubricating oil cooler
W 16-01-01 Removing and installing the oil suction pipe Oil suction pipe
W 17-01-01 Removing and installing the control block High-pressure pump
W 17-01-04
Removing and installing the high-pressure pump
(Installation position A)
High-pressure pump
W 17-01-05
Removing and installing the high-pressure pump
(Installation position B)
High-pressure pump
W 19-01-01 Removing and installing the injector Injector
W 20-01-01 Removing and installing the fuel filter console Fuel filter
W 20-02-01
Removing and installing the fuel supply pump (V-
belt drive)
Fuel pump
W 21-02-01 Removing and installing the rail Fuel pipes
W 21-02-03 Removing and installing the pressure limiting valve Fuel pipes
W 21-02-05 Removing and installing the rail pressure sensor Fuel pipes
W 22-01-01 Removing and install the charge air line Charge air line
W 37-03-01
Removing and installing the coolant pump (V-belt
drive)
Coolant pump
W 38-01-01 Removing and installing the thermostat Thermostat housing
W 38-01-02 Checking the thermostat (in the removed state) Thermostat housing
W 38-02-01 Removing and installing the thermostat housing Thermostat housing
W 39-01-01
Removing and installing the belt tensioner (V-rib
belt)
Fan drive
W 39-02-01
Removing and installing the fan drive
Fan drive
W 3
9-02-03 Dismantling and assembling the fan drive Fan drive
W 39-04-03
Removing and installing the fan console (V-rib belt
drive)
Fan console
Job card Activity Maintenance group
