DeVilbiss 525 Series - Important Parts of Your Concentrator; Front View (Figure A); Back View (Figure B); Accessories

EN - 7
Front View (Figure A)
1. Operating instructions (LED indicator panel)
2. Power Switch
| = ON
O = OFF
3. Flow meter knob
4. Flow meter
5. Circuit breaker – resets the unit after electrical overload shutdown
6. Oxygen outlet tting – oxygen is dispersed through this port
7. Normal Oxygen (green) light (see page 9)
8. Low Oxygen (yellow) light (see page 9)
9. Red Service Required (red) light – when illuminated contact your DeVilbiss
provider
10. Hour meter
Back View (Figure B)
11. Handgrip
12. Exhaust Vents
WARNING
When the device is used under extreme operating or single fault
conditions, the exhaust air near the exhaust vents on the bottom of
the unit may exceed 41˚. Keep exposed body parts, such as hands
and feet, a minimum of 46 inches (1.2 meters) away from the exhaust
vents to avoid the risk of burns.
 
14. Line cord strap
15. Filter Door with venting and compartment for optional gross particle lter
16. Auxiliary Oxygen Port (Serial numbers starting with R, N, or B): Your
concentrator is equipped with an auxiliary oxygen port that can be used to ll
oxygen cylinders with an FDA-cleared cylinder lling device that is designed
to use oxygen from a concentrator to ll a cylinder. The port is only for use
with FDA-cleared lling devices with compatible oxygen input specications.
Refer to the cylinder lling device instruction guide for the oxygen input/output
specications, connection and operating instructions.
1
2
3
4
5
6
A
11
12
13
12
14
11
15
B
16
10
7
9
8
IMPORTANT PARTS OF YOUR CONCENTRATOR
Please take time to familiarize yourself with your DeVilbiss oxygen concentrator before operating.
Accessories
Transfiller Caddy ........................................................................................................................................................................................................................DeVilbiss 525DD-650
Bubble Humidifier ........................................................................................................................................................................................................ Salter Labs 7600 or equivalent
There are many types of humidiers, oxygen tubing and cannulas/masks that can be used with this device. Certain humidiers and accessories may impair the device’s
performance. A mask or any nasal cannula can be used with continuous ow delivery and may be sized according to your prescription as recommended by your homecare
provider who should also give you advice on the proper usage, maintenance and cleaning.
WARNING
The accessories (nasal cannula, masks, oxygen tubing, humidiers, etc.) that supply oxygen to the patient must be equipped with a means that, in case of re,
stops the propagation of re through the accessory for the safety of the patient and others. A re activated ow-stop or thermal fuse device, if available, should be
used with the oxygen supply accessories. These types of ow-stop devices stop the ow of oxygen to the patient in the event of re. This means of re protection
should be located as close to the patient as practicable.
WARNING
When using the Transller Caddy with a Transll device, always keep the system on a at surface. Disassemble the system prior to moving.
NOTE – The bubble humidier should be supplied with a permanent re stop device. If a bubble humidier needs to be used without a permanent re stop device, a
secondary re stop device must be used and placed as close to the humidier as possible. Failing to do so could increase the risk of re. Country Standards may vary. Please
contact your provider for information.
NOTE – A maximum of 50 feet (15 meters) of crush-proof oxygen tubing, plus 7 feet (2.1 meters) of cannula, plus a bubble humidier is allowed between the concentrator
and the patient.
NOTE – The oxygen supply accessory (patient tubing) shall be equipped with a means that, in case of re, stops the delivery of
oxygen to the patient. This means of protection should be located as close to the patient as practicable. Country Standards may
vary. Please contact your provider for information.
NOTE – Your healthcare provider should verify the compatibility of the oxygen concentrator and all of the parts used to connect to the patient before use.
SE-525KS-1
