DeVilbiss 7305 SERIES - Important Parts Identification

EN - 4 SE-7305
7
1
2
8
9
10
5
3
4
IMPORTANT PARTS
7305 Series DeVilbiss Suction Unit
Disposable Container with Internal Filter Cartridge and
Splash Guard
1. 43/8” connection tubing
2. Filter cartridge (Do not get wet)
3. Lid
4. Jar
5. Splash guard
6. Patient tubing connector
Reusable Container with External Bacteria Filter
1. 43/8” connection tubing
2. Lid with o-ring
3. Overowvalve
4. Jar
5. Patient tubing connector
6. Connection elbow
7. Bacterialter
With Disposable Container and Internal Filter Cartridge
1. 43/8” connection tubing
2. Vacuum gauge
3. Vacuum regulator knob
4. DC power input (on side)
5. Power switch
6. Splash guard
7. Collection container
8. Lid
9. Patient tubing
10. Filter cartridge
AC to DC Adapter (not shown)
DC power cord (not shown) optional
Internal rechargeable battery (not shown) 7305P series only
Carrying case (not shown) 7305P series only
With Reusable Container and External Bacteria Filter
1. Externalbacterialter
2. Vacuum gauge
3. 4
3/8” connection tubing
4. Vacuum regulator knob
5. DC power input (on side)
6. Power switch
7. Collection container
8. Lid
9. Patient tubing
10. Connection elbow
AC to DC Adapter (not shown)
DC power cord (not shown) optional
Internal rechargeable battery (not shown) 7305P series only
Carrying case (not shown) 7305P series only
7
3
8
9
1
6
4
5
10
2
6
7305 Series DeVilbiss Containers
1
5
3
6
2
4
7
1
2
5
3
4
6
