DeVilbiss 7305 SERIES - LED Indicators and Operation; LED Explanations; Battery Charging Procedures; Cleaning Instructions

EN - 7SE-7305
NOTE–Do not use any cleaners or disinfectants that contain ammonia, benzene and/or acetone to clean the unit.
Tubing (single-patient use)
1. Disconnect the tubing from the unit.
2. Rinse thoroughly by running warm tap water through it.
3. Followbysoakinginasolutionof1partvinegar(>=5%aceticacidconcentration)to3partswater(131ºF-149ºF/55ºC-65ºC)for60minutes.Rinsewithclean,warmwater
and air dry.
4. Keep the outer surface of the tubing clean by wiping with a clean, damp cloth.
Carrying Case (single-patient use)
1. Wipe the case using a clean cloth dampened with detergent and/or disinfectant.
NOTE– Disinfection information is based on AARC Clinical Practice Guideline Suctioning of the Patient in the Home.
Suction Unit (multi-patient use)
Device Cleaning and Disinfection When There is a Patient Change
When medical devices have already been used with a patient, contamination with human pathogenic germs should be assumed (unless there is evidence to the contrary), and
the next patient, user or third party should be protected by appropriate handling and preparation. Therefore, when there is a patient change, people must be protected during
the transport and handling of the device and the device must be fully processed, i.e., cleaned and disinfected, by suitably trained personnel before reuse to protect the next
patient.ThecompleteprocessingmayonlybedonebythemanufacturerorbyaqualiedDeVilbissprovider/servicetechnician.
NOTE – When the unit is used as per instructions under normal conditions the interior of the unit is protected from exposure to pathogens by the in-line lter on the collection
container, hence no disinfection of internal components is necessary.
NOTE – If the unit is used without an in-line lter then the interior of the unit has been exposed to pathogens and the unit cannot be disinfected.
NOTE – If the following processing of the unit by a qualied DeVilbiss provider/technician is not possible, the unit must not be used by another patient!
DeVilbissHealthcarerecommendsthatatleastthefollowingproceduresbecarriedoutbythemanufactureroraqualiedthirdpartybetweenusesbydifferentpatients.
1. Disposeofallaccessorycomponentsthatarenotsuitableforreuse,i.e.,collectioncontainer,lter,tubingandcarryingcase.
2. With the power switch in the “Off” position, disconnect the DeVilbiss Suction Unit from all external power sources.
3. Visually inspect unit for any damage, missing parts, etc.
4. Wipe the housing with a clean cloth and a commercial (bacterial-germicidal) disinfectant that meets the requirements listed in the NOTE below and is used as per the
disinfectant manufacturer’s recommended dilution rates and instructions.
CAUTION – Do not submerge in water as this will result in damage to the vacuum pump.
NOTE – Do not use any cleaners or disinfectants that contain ammonia, benzene and/or acetone to clean the unit.
MAINTENANCE
Inspect suction tubing and container for leaks, cracks, etc. before each use.
DANGER
Electric shock hazard. Do not attempt to open or remove cabinet, there are no user-serviceable internal components. If service is required, return unit to a
qualied DeVilbiss Healthcare provider or an authorized service center. Opening or tampering with the unit will void warranty.
Changing Filter Cartridge (single-patient use) Disposable Container
1. Changeltercartridgeifoverowoccursoreverytwomonths,whichevercomesrst.
2.
Turn unit
“off”.
3. Removeltercartridgeand43/8” tubing.
4. Install new cartridge and tubing.
NOTE– Do not substitute any other material for this lter cartridge. Substitution may lead to contamination or poor performance; use only DeVilbiss lter cartridges.
NOTE– The lter cartridge contains a hydrophobic lter. If the lter media becomes wet, air ow will be stopped. The lter cartridge must then be replaced. Do not remove lter
media from lter cartridge.
NOTE– Filter cartridges are included with each disposable container. They are also available separately (7305D-635 12/pack).
Changing Bacteria Filter (single-patient use) Reusable Container
1. Changebacterialterifoverowoccursoreverytwomonths,whichevercomesrst.
2. Removelterbydisconnectingitfromsuctionunitandlidassembly.
3. ReplacewithacleanDeVilbissbacterialter(non-sterile)andremounttosuctionunitandlid.Ensurethattheclearsideofthebacterialteristowardelbowand
containerwheninstalling/re-installing.Donotreversedirectionoflter.Additionallters(7305D-60812/pack)maybepurchasedfromyourauthorizedDeVilbiss
Healthcare provider.
NOTE– Do not substitute any other material for this bacteria lter. Substitution may lead to contamination or poor performance; use only DeVilbiss lters.
NOTE– Bacteria lter must be changed between patients.
PROVIDER’S NOTES
No routine calibration or service is required provided the device is used in accordance with the manufacturer’s directions. In case of a change of patient, the device must be
reconditioned to protect the user. Reconditioning must only be carried out by the manufacturer or service provider. Between patients:
1. Visually inspect unit for any damage, missing parts etc.
2. Ensure that unit and accessories are clean.
3. UseanindependentvacuumgaugetoverifytheunitprovidesthepropervacuumlevelasstatedinSpecications.
4. Discardandreplacecollectioncontainer,lter,andtubingbetweenpatients.
5. Wipe the surface using a clean cloth dampened with disinfectant.
