EN - 8 SE-7305
TROUBLESHOOTING
NOTE– Your DeVilbiss Suction Unit contains no user-serviceable parts. If you believe your unit is not working properly, BEFORE YOU RETURN IT TO THE HOME MEDICAL
EQUIPMENT PROVIDER WHERE YOU PURCHASED IT, please take a few moments to check for these possible causes:
PROBLEM ACTION
Unit does not turn on, but green external power light is
illuminated.
1. Check power sources and connections.
2. Ensure wall outlet is live by plugging in a lamp.
3. If running from an internal battery, ensure that your unit has a battery installed.
4. If battery is installed, check that it is fully charged.
Pump runs, but there is no vacuum. 1. Check that all tubing is connected properly.
2. Check tubing connections for breaks or leaks.
3. Ensurethatoatshut-offisnotactivated.
4. Check for leaks or cracks in container assembly.
Low vacuum. 1. Use vacuum adjustment knob to increase vacuum level.
2. Check system for leaks.
3. Push vacuum adjustment knob in toward unit and then release.
Battery will not charge but charge light is illuminated. 1. Ensure that unit is equipped with an internal battery by contacting your DeVilbiss equipment provider.
2. Verify that charge light turns on.
3. Check electrical connections during charging.
4. Ensure wall outlet is live by plugging in a lamp.
SPECIFICATIONS/CLASSIFICATIONS
Size H x W x D inches (cm)
7305P & 7305D Series 9.0 x 7.0 x 8.0 (22.9 x 17.8 x 20.3)
Weight lb. (kg)
7305D Series 3.8 (1.7)
7305P Series 6.3 (2.9)
Electrical Requirements
100-240 V AC 50/60 Hz .75 A max; 12 V DC, 33 W max
Internal Rechargeable Battery
7305P Series Factory Equipped
7305D Series Not Factory Equipped (provider-installed option)
Vacuum Range
(NOTE– Using Flovac Liners may impair the device’s performance.)
7305P & 7305D Series 80 to 550 mm Hg
Air Flow @ pump inlet: 27LPM(freeow)typical(maybelesswhenrunningfrominternalbattery)
Container Capacity
7305 D & P Series 800 ml (cc) Disposable
7305 D & P Series - Optional 1200 ml (cc) Reusable
Environmental Conditions
Operating Temperature Range 32°F (0°C) - 104°F (40°C)
Operating Relative Humidity 0-95%
Operating Atmospheric Pressure 10.2 psi (70 kPa) - 15.4 psi (106 kPa)
Storage & Transport Temperature Range -40°F (-40°C) - 158°F (70°C)
Storage & Transport Relative Humidity 0-95%
Storage & Transport Atmospheric Pressure 7.3 psi (50 kPa) - 15.4 psi (106 kPa)
Warranty
7305P Series Two-years limited, excluding internal battery and container
7305D Series Two-years limited, excluding container
Internal Battery 90-day
Approvals
7305D & 7305P Series IEC 601-1; CAN/CSA-C22.2 No. 601.1-M90; UL 60601-1, EN 60601-1-2
7305P meets RTCA/D-160D DO-160D - section 21 Category M For battery operation only Airline use
Equipment Classications
With respect to protection from electric shock Class II. Class I using 7305P-613 power supply
Degree of protection against electric shock Type BF Applied Parts
Degree of protection against ingress of liquids IPX2 and ordinary power supply
Mode of Operation Intermittent Operation: 30 minutes on, 30 minutes off
Equipmentnotsuitableforuseinthepresenceofaammableanestheticmixturewithairorwithoxygenornitrousoxide.
ISO Classication
7305PSeriesonly-ElectricallypoweredmedicalsuctionequipmentforeldandtransportuseaccordingtoISO10079-1:1999
High Flow/High Vacuum
7305D Series - Electrically powered medical suction equipment for non-transport use according to ISO 10079-1 : 1999
