9- ENG
D26805
GLOSSARY
Become familiar with these terms before operating the unit.
CFM: Cubic feet per minute.
SCFM: Standard cubic feet per minute; a unit of measure of air delivery.
PSIG: Pounds per square inch gauge; a unit of measure of pressure.
Code Certification: Products that bear one or more of the following marks:
UL, CUL, ETL, CETL, have been evaluated by OSHA certified independent
safety laboratories and meet the applicable Underwriters Laboratories
Standards for Safety.
Unloader Blow-Off Pressure: All models are continuous running units
controlled by tank pressure. When the maximum tank pressure is obtained, the
unloader valve will blow-off. This will cause the compressor to exhaust the air
to the atmosphere and not the tank. This decreases the load on the engine and
allows it to run at a near no-load condition.
Unloader Reset Pressure: When the tank pressure drops to a predetermined
point, the unloader valve closes. The tank pressure will now increase until it
reaches the unloader blow-off pressure.
ON-RECEIPT INSPECTION
Each air compressor outfit is carefully checked before shipment. With improper
handling, damage may result in transit and cause problems in air compressor
operation.
Immediately upon arrival, check equipment for both concealed and visible
damages to avoid expenses being incurred to correct such problems. This
should be done regardless of any visible signs of damage to the shipping
container.
Report any damages to carrier and arrange for inspection of goods
immediately.
For the location or a listing of the nearest Authorized Warranty Service Center,
call our toll free number at 1-800-888-2468, Ext. 2.
Accessories for this unit are available at the store the unit was purchased.
ACCESSORIES
ASSEMBLY
Contents of Carton
1 - Air Compressor
1 - Thread Sealant Tape
1 - Screw .250-20 .625 Set Square
1 - Shut-off Valve 1/4" NPT
1 - Engine Manual
1 - Owner's Manual
1 - Parts Manual
4 - Vibration Mount
8 - Lock Washer
4 - Flat Washer
Tools Required for Assembly
1 - a 9/16" socket or open-end wrench for attaching the wheels
1 - a 7/16" open-end wrench for attaching the rubber feet
1 - a 1/4" open-end wrench for attaching the shut-off valve and air outlet adapter.
8 - Hex Nut .313-18 UNC
2 - Cap Screw
2 - Hex Nut .250-20 UNC
2 - Hex Nut .375-16 UNC
2 - Rubber Feet
2 - Shoulder Bolt
2 - Lock Washer
1 - Handle
2 - Wheel
