Devolo dLAN 550+ WiFi User Manual

Network configuration 41
devolo dLAN 550+ WiFi
is protected against unauthorised access with
your custom password!
햳 Call up the configuration interface again later; the
following window appears first:
햴 Enter admin in the User name field and your
custom password in the Password field.
The admin user name is set by default
and cannot be changed.
4.6.3 Network settings
As a component of your network, the dLAN 550+ WiFi
also communicates via the TCP/IP protocol. The IP ad-
dress required for this can either be entered manually
or obtained automatically from a DHCP server.
The option Network settings are automatically
retrieved from a DHCP server is enabled by default.
If a DHCP server is already present in
the network for giving out IP addres-
ses, have this option enabled so that
the dLAN 550+ WiFi automatically
receives an address from it. This is
usually the router.
To assign a static IP address, first disable the option
Network settings are automatically retrieved
from a DHCP server and make your individual
entries.
Save your entries with OK.
If you happen to forget the IP address of your
dLAN 550+ WiFi, proceed as described under
4.1 Calling up the built-in configuration in-
terface.
4.6.4 System
Here you can reset the current configuration to the fac-
tory defaults, save it to your computer as a file or resto-
re it from there and update the firmware of the
dLAN 550+ WiFi.

Devolo dLAN 550+ WiFi Specifications

General

Built-in power socket	Yes
Ethernet LAN (RJ-45) ports	3
WLAN data transfer rates supported	300 Mbit/s
Product color	White
Quantity per pack	2 pc(s)
Harmonized System (HS) code	85171800
