29 Network configuration
devolo Magic 1 WiFi mini
4 Network configuration
The devolo Magic 1 WiFi mini has a built-in web in-
terface that can be called up using a standard web
browser. All settings for operating the device can
be modified here.
4.1 Calling up the built-in web
interface
You can access the built-in online web interface for
the devolo Magic 1 WiFi mini in different ways:
b Using the devolo Home Network App on your
smartphone or tablet, you can access the
device's web interface by going to the
devolo Home Network App overview page
and tapping on the gear/arrow.
You can find more information on
devolo Home Network App in Chapter 3.4 In-
stallation of devolo software.
or
b Using the Cockpit software under Start  All
Programs  devolo devolo Cockpit, you
can get to the device's web interface by clic-
king on the corresponding tab for the
devolo Magic 1 WiFi mini. Then the program
determines the current IP address and starts
the configuration in the web browser.
By default, the web interface will open direct-
ly. However, if an access password has been
set via the option System  Management,
you have to enter that password first. Read
more about this under 4.7 System.
4.2 General information about
the menu
All menu functions are described in the correspon-
ding interface as well as in the associated chapter
in the manual. The sequence of the description in
the manual follows the structure of the menu. The
figures for the device interface serve as examples.
Logging in
The web interface is not password protected. As-
signing a login password is mandatory when log-
ging in for the first time to prevent unauthorised
access by third parties.
Magic_1_WiFi_mini.book Seite 29 Mittwoch, 16. Oktober 2019 11:27 11

Devolo Magic 1 WiFi mini Specifications

General

Modulation	64-QAM, 256-QAM, 1024-QAM, 4096-QAM, BPSK, DSSS, OFDM, QPSK
Power plug	Type C
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES, WPA, WPA2, WPS, WPS-PBC, WPS-PIN
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Built-in power socket	No
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Maximum data transfer rate	1200 Mbit/s
Maximum operating distance	400 m
Ethernet LAN interface type	Fast Ethernet
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
WLAN data transfer rates supported	300 Mbit/s
Certification	CE
Product color	White
LED indicators	PLC, WLAN
Cables included	LAN (RJ-45)
Quantity per pack	- pc(s)
AC input voltage	196 - 250 V
AC input frequency	50 Hz
Power consumption (standby)	1 W
Power consumption (typical)	4.4 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks
Linux operating systems supported	Ubuntu 16.04, Ubuntu 16.10, Ubuntu 17.10
Mobile operating systems supported	Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 13
Windows operating systems supported	Windows 10, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	41 mm
Width	68 mm
Package depth	231 mm
Package width	190 mm
Package height	92 mm
Package weight	670 g
