31 Network configuration
devolo Magic 1 WiFi mini
Help text blank fields
Fields that have not been filled in yet contain grey-
ed out help text, which indicates the required con-
tent for the field. This help text disappears
immediately once content has been entered.
Default settings
Some fields contain default settings which ensure
the greatest amount of compatibility and ease of
use. Default settings are identified with an * in
drop-down menus.
Default settings can of course be replaced with cu-
stomised information.
Recommended settings
Some fields include recommended settings.
Recommended settings can of course be replaced
with customised information.
Tables
You can make changes within a table by clicking
the corresponding table row in Time Control and
Parental Control. In edit mode, the corresponding
table rows have a blue background. In edit mode,
the corresponding table rows have a blue
background.
Invalid entries
Entry errors are either highlighted by a red border
or error messages are shown.
Buttons
Click the Disk icon to save the settings for the
respective web interface area.
Click the X icon or use the Menu path above the
buttons to exit the respective web interface area.
Click the Recycle bin icon to delete an entry.
Click the Arrow icon to refresh a list.
Magic_1_WiFi_mini.book Seite 31 Mittwoch, 16. Oktober 2019 11:27 11

Devolo Magic 1 WiFi mini Specifications

General

Modulation	64-QAM, 256-QAM, 1024-QAM, 4096-QAM, BPSK, DSSS, OFDM, QPSK
Power plug	Type C
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES, WPA, WPA2, WPS, WPS-PBC, WPS-PIN
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Built-in power socket	No
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Maximum data transfer rate	1200 Mbit/s
Maximum operating distance	400 m
Ethernet LAN interface type	Fast Ethernet
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
WLAN data transfer rates supported	300 Mbit/s
Certification	CE
Product color	White
LED indicators	PLC, WLAN
Cables included	LAN (RJ-45)
Quantity per pack	- pc(s)
AC input voltage	196 - 250 V
AC input frequency	50 Hz
Power consumption (standby)	1 W
Power consumption (typical)	4.4 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks
Linux operating systems supported	Ubuntu 16.04, Ubuntu 16.10, Ubuntu 17.10
Mobile operating systems supported	Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 13
Windows operating systems supported	Windows 10, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	41 mm
Width	68 mm
Package depth	231 mm
Package width	190 mm
Package height	92 mm
Package weight	670 g
