DeWalt D25900K Service Manual

Page 24 of 63
q Remove Circlip (37)
q Push Bearings(41) and Spacers (39,40) through from the large gear side using a
press and a suitable size drift.
q Remove the Main casting from the service jig
q Remove the CrankShaft assembly using a press.
q Push through from the outside.
The CrankShaft bearings can not be replaced due to
misalignment problems when refitting. If required the
complete housing will have to be replaced.

DeWalt D25900K Specifications

General

Input power	1500 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Impact rate	2040 bpm
Impact energy (max)	25 J
Chuck type	SDS Max

Weight and Dimensions

Weight	9800 g
