SECTION FOUR.
Routine Servicing
When the unit comes in to Service for changing the brushes, typically after 250 to
300 hrs.
The following items should be carried out.
- Replace O-Ring 487213-00 (49) on Piston.
- Replace O-Ring 323711-44 (79) on Main Housing.
- Replace O-Ring 487296-00 (77) on Ram.
- Replace O-Ring 487297-00 (73) inside Cylinder.
- Replace O-Ring 487299-00 (109) inside Spindle
- Replace Seal 487243-00 (108) inside Spindle.
- Lubricate all the above and replace the Grease 578970-02 140g (800) in the
Gearbox and Crankcase.
- Replace Washer 487241-00 (89) & Snap Ring 487205-00 (88).
- Replace rubber - nose 487238-00 (87)
- Replace Brushes 487340-00 230v or 487340-01 115v.

DeWalt D25900K Specifications

General

Input power	1500 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Impact rate	2040 bpm
Impact energy (max)	25 J
Chuck type	SDS Max

Weight and Dimensions

Weight	9800 g
