42
Part # 8533-053-001 REV 4/09
Electronic Acceptor Coin Drop
Setting the electronic coin acceptor switches
Some washer models come equipped with an electronic coin acceptor. Follow the instructions below for
setting the switches for the desired country and currencies.
1. The electronic coin acceptor has switch settings depending on the coins and country. See the table
below for available values of the left and right coin inputs for the available countries.
WARNING: turn power off before and leave power off when changing the switches of
the electronic coin acceptor.
2. Turn power back on and test coins to ensure proper operation.
NOTE: Coins and tokens in the left coin column will result in one pulse to the left coin input.
NOTE: The $1, 500¥, 50NT, and $10 coins in the right coin column will result in one pulse to
the right coin input, while the $2 coins will result in two pulses to the right coin input.
Note: Acceptance of multiple coins per country and multiple tokens is allowed. Only the down/
off setting for each coin and token is required to accept that coin or token.
Acceptor P/N Country Left Coin
Right
Coin
SWs 1-8 SWs 9-16
9021-010-001 Canada 25¢
↓↓↑↑↑↑↑↓ ↓↑↑↑↑↑↑↓
Canada $1
↑↑↓↓↓↑↑↓ ↓↑↑↑↑↑↑↓
Canada $2
↑↑↑↑↑↓↓↓ ↓↑↑↑↑↑↑↓
Japan 100¥
↓↓↑↑↑↑↑↓ ↑↓↑↑↑↑↑↓
Japan 500¥
↑↑↓↓↑↓↓↓ ↑↓↑↑↑↑↑↓
Taiwan 10NT
↓↓↑↑↑↑↑↓ ↑↑↓↑↑↑↑↓
Taiwan 50NT
↑↑↓↓↑↓↓↓ ↑↑↓↑↑↑↑↓
Korea 500W
↓↓↑↑↑↑↑↓ ↑↑↑↓↑↑↑↓
Greenwald 118-1 Token
↑↑↑↑↑↑↑↓ ↑↑↑↑↓↑↑↓
Greenwald 118-5 Token
↑↑↑↑↑↑↑↓ ↑↑↑↑↑↓↑↓
U.S.A. 25¢
↓↓↑↑↑↑↑↓ ↑↑↑↑↑↑↓↓
U.S.A. $1
↑↑↓↓↑↑↑↓ ↑↑↑↑↑↑↓↓
9021-011-001 Australia 10¢
↓↓↑↑↑↑↑↓ ↑↓↑↑↑↑↑↓
Australia 20¢
↑↑↓↓↑↑↑↓ ↑↓↑↑↑↑↑↓
Australia $1
↑↑↑↑↓↓↑↓ ↑↑↓↑↑↑↑↓
Australia $2
↑↑↑↑↑↑↓↓ ↓↑↓↑↑↑↑↓
New Zealand 10¢
↓↓↑↑↑↑↑↓ ↑↓↑↑↑↑↑↓
New Zealand 20¢
↑↑↓↓↑↑↑↓ ↑↓↑↑↑↑↑↓
New Zealand $1
↑↑↑↑↓↓↑↓ ↑↑↑↓↑↑↑↓
New Zealand $2
↑↑↑↑↑↑↓↓ ↓↑↑↓↑↑↑↓
Hong Kong $5
↓↓↓↓↑↑↑↓ ↑↑↑↑↓↑↑↓
Hong Kong $10
↑↑↑↑↓↓↑↓ ↑↑↑↑↓↑↑↓
Greenwald 118-1 Token
↑↑↑↑↑↑↑↓ ↑↑↑↑↑↓↑↓
Greenwald 118-5 Token
↑↑↑↑↑↑↑↓ ↑↑↑↑↑↑↓↓
