105
Part # 8533-053-001 REV 4/09
Section 8:
Parts Data
A-Series Accessories
WCAD18KCS-10 120 volts 60hz. Single Phase
WCAD18KCS-12 208-240 volts 60hz. Single Phase or Three Phase
WCAD25KCS-12 208-240 volts 60hz Single Phase or Three Phase
WCAD40KCS-12 208-240 volts 60hz Single Phase or Three Phase
WCAD55KCS-12 208-240-volts 60hz Single Phase or Three Phase
WCAD75KCS-12 208-240 volts 60 hz Single Phase or Three Phase
Key Description T-300 T-400 T-600 T-900 T-1200 QTY
* Kit, Door Gasket Expander (large) 9732-139-002 9732-139-002 9732-139-002 9732-139-002 9732-139- 002
* Kit, Door Gasket Expander (small) 9732-139-001 9732-139- 001 9732-139-001 9732-139-001 9732-139-001
* Hose, Water Supply 3/8” I.D. x 48 9990-027-011 9990-027-011 9990-027-011 2
* Hose, Water Supply 5/8” I.D. x 48 9990-027-013 9990-027-013 2
* Washer, Inlet Hose (furnished) 8641-242-000 8641-242-000 8641-242-000 8641-242-000 8641-242-000 2
* Strainer, Inlet Hose (furnished) 9565-003-001 9565-003-001 9565-003-001 9565-003-001 9565-003-001 2
* Drain hose 10 ft. length x 2-1/4” I.D 9242-417-002
* Drain hose 10 ft. length x 3” I.D. 9242-417-003 9242-417-003 9242-417-003 9242-417-003 9242-417-003
* Bevel Washer for 5/8” bolt used in
installations using angle iron bases
8641-586-002 8641-586-002 8641-586-002 8641-586-002 8641-586-002
* Bevel Washer for 3/4” bolt used in
installations using angle iron bases
8641-586-003 8641-586-003 8641-586-003 8641-586-003 8641-586-003
* Sealing compound 8538-151-001 8538-151-001 8538-151-001 8538-151-001 8538-151-001
* TORX#20 8545-051-002 8545-051-002 8545-051-002 8545-051-002 8545-051-002
* Special Tool For Removing Coin
Acceptor Mounting Screws. (T-10
Torx)
8545-051-003 8545-051-003 8545-051-003 8545-051-003 8545-051-003
* Flow Restrictors (in dispenser ) 9475-002-002 9475-002-002 9475-002-002 9475-002-002 9475-002-003 2
* Battery (used on Control PCB) 8612-001-001 8612-001-001 8612-001-001 8612-001-001 8612-001-001
* Special Tool for adjusting spac-
ing between outer tub front and
cylinder front
8545-056-001 8545-056-001
* VFD Filter options (1 phase) 120v 9732-233-001
* VFD Filter options (3 phase) 9732-234-001 9732-231-001 9732-231-001 9732-255-001 9732-256-001
* VFD Filter options (1 phase) 9732-235-001 9732-232-001 9732-232-001 9732-230-001 9732-251-001
* Puller for pushing cylinder out of
bearings must be purchased from
local sources.
* Clamps to hold tub front to outer
tub when installing tub front
Vise Grip #11R Vise Grip #11R
* Coin Bearing & Seal Kit 9732-219-001 9732-219-002 9732-219-004 9732-219-006 9732-219-006
* Coin Op CD with OS2 Platform for
A Series Washers Only
9504-015-001 9504-015-001 9504-015-001 9504-015-001 9504-015-001
106
Part # 8533-053-001 REV 4/09
106
