Dexter Laundry A Series Parts & Service Manual

A-Series Kits & Assemblies
Description Part Number
Kit - Replaces the 9376-301-001 motor
V & A series conversion to manual start for small vault
Emergency Stop Button Kit w/ button and switch Assembly
Cylinder Weld Assembly with seals
Cylinder Weld Assembly with seals
9732-325-001
9732-224-001
9732-223-001
9732-120-001
9732-119-001
Wiring Harness Part # by Model
Key Description T-300 T-400 T-600 T-900 T-1200 QTY
* Wiring Harness (Add Bleach Lite
assy included)
9794-001-001 9794-001-001 9794-001-001 9794-001-001 9794-001-001 1
* Wiring Harness, Door Lock 9627-791-003 9627-791-003 9627-791-004 9627-791-004 9627-791-004 1
* Wiring Harness,CoinDrop Mech 9627-792-001 9627-792-001 9627-792-001 9627-792-001 9627-792-001 1
* Wiring Harness,
Drain,Thermo,DoorSol
9627-796-001 9627-796-001 9627-796-002 9627-796-002 9627-796-002 1
* Data Cable 9806-015-001 9806-015-001 9806-015-001 9806-015-001 9806-015-003 1
* Wiring Harness P20/P21 9627-793-001 9627-793-001 9627-793-001 9627-793-001 9627-793-001 1
* Wiring Harness P8/P16 9627-794-001 9627-794-001 9627-794-001 9627-794-001 9627-794-001 1
* Wiring Harness WaterValve/P19 9627-795-001 9627-795-001 9627-795-002 9627-795-002 9627-795-002 1
* Wiring Harness LED PCB 9627-797-001 9627-797-001 9627-797- 001 9627-797-001 9627-797- 001 1
* Wiring Harness P5/pressure 9627-800-001 9627-801-001 9627-802-001 9627-803-001 9627-803-001 1
* Wiring Assembly Yel. 32” 8220-064-023 8220-064-023 8220-064-023 8220-064-023 2
* Wiring Assembly Yel. 64” 8220-064-040 2
* Wiring Assembly Red 20” 8220-001-282 8220-001-282 2
* Wiring Assembly Red 41” 8220-062-032 2
* Wiring Assembly Vio. 24” 8220-118 -001 8220 -118- 001 8220-118 -001 2
* Wiring Assembly Wht/Brn 8” 8220-108-007 1
* Wiring Assembly Jumper Yel 8220-123-001 8220-123-001 8220-123-001 8220-123-001 8220-128-001 1
* Wire Red Yellow 8” 8220-108-008 1
* Wire Yellow Jumper (water valve) 8220-119-002 1
* 75lb Washer Dispenser Label 8502-687-001 1
* Wiring Assembly Red 28” 8220-062-025 8220-062-025 2
* Wiring Assembly Blk. 17” 8220-062-028 8220-062-028 8220-062-028 8220-062-028 8220-062-028 1
* Wiring Assembly Red 17” 8220-062-027 8220-062-027 8220-062-027 8220-062-027 8220-062-027 1
* Wiring Assembly Jumper BLK. 8220-117-002 8220-117-002 8220-117-002 8220-117-003 2
* Wiring Assembly Red 7” 9631-381-018 9631-381-018 9631-381-018 9631-381-018 9631-381-018 1
* Wiring Assembly Blu/Wht 8220-090-009 8220-090-009 8220-090-009 8220-090-009 8220-090-009 1
* Wiring Assembly Blk/Blu 8220-001-231 8220-001-231 8220-001-231 8220-001-231 8220-001-231 1
* Wire Assembly Green 7” 8220-001-478 1
* Harness Power Terminal Block 9627-831-001 9627-747-003 9627-747-003 9627-747-002 9627-747-002 1
* Wire Red Yellow 8” 8220-108-008 1
* Wire Yellow Jumper (water valve) 8220-119-002 1
107
Part # 8533-053-001 REV 4/09
107
