16
8514-300-001 REV PR
6 Unit Specificaons
6.1 Vended Washer Specificaons
Vended Washers T-300 T-400 T-600 T-900
Capacity Dry Weight Capacity - lb (kg) 20 (9.1) 30 (13.6) 40 (18.1) 60 (27.2)
Cylinder Volume - cu ft (L) 2.7 (76.5) 4 (113.3) 6 (170) 9 (254.9)
Speed High Extract Speed - g (RPM) 100 (579) 100 (532) 100 (532) 100 (485)
Intermediate Extract Speed - g (RPM) 60 (449) 60 (412) 60 (412) 60 (375)
Washing Speed - g (RPM) 0.9 (55) 0.9 (50) 0.9 (50) 0.9 (43)
Motor Size - hp (kW) 1 (0.75) 2 (1.5) 2 (1.5) 3 (2.2)
Dimensions Cabinet Height - in (cm)
43
7/8 (111.4)
48
3/16 (122.4)
49
11/16 (126.2)
55
3/8 (140.7)
Cabinet Width - in (cm) 26 (66) 29 7/8 (75.9) 29 7/8 (75.9)
34
3/8 (87.3)
Cabinet Depth - in (cm) 25 (63.5) 27 3/8 (69.5) 36 (91.4)
38
7/8 (98.8)
Door Opening - in (cm)
12
1/4 (31.1) 15 1/4 (38.7) 15 1/4 (38.7)
19
1/4 (48.9)
Floor to Door Bottom - in (cm)
14
7/8 (37.8) 16 1/4 (41.3) 16 1/4 (41.3) 16 (40.6)
Cylinder Diameter - in (cm) 21 (53.3) 25 (63.5) 25 (63.5) 30 (76.2)
Cylinder Depth - in (cm)
13
1/2 (34.3) 14 1/8 (35.9) 21 1/8 (53.7) 22 (55.9)
Weight Net Weight - lb (kg) 317 (143.8) 432 (196) 558 (253.1) 964 (437.3)
Shipping Shipping Weight - lb (kg) 340 (154.2) 450 (204.1) 580 (263.1) 980 (444.5)
Shipping Height - in (cm) 50 (127) 53 1/4 (135.3) 54 3/4 (139.1)
61
1/2 (156.2)
Shipping Width - in (cm)
27
1/4 (69.2) 31 1/2 (80) 31 1/2 (80) 36 (91.4)
Shipping Depth - in (cm)
30
1/2 (77.5) 33 1/2 (85.1) 41 (104.1)
44
1/4 (112.4)
Water Water Inlet Size - in (mm) 3/4 (19) 3/4 (19) 3/4 (19) 3/4 (19)
Pressure (min-max) - psi (kPa)
30-
120
(207-
827) 30-120
(207-
827) 30-120
(207-
827)
30-
120
(207-
827)
Flow Rate - gal/min (L/min) 9 (34) 9 (34) 9 (34) 9 (34)
Approx. Water Usage Per - gal (L) 15.8 (59.8) 23.5 (89) 35.1 (132.9) 52.6 (199.1)
Drain Diameter (O.D.) - in (cm) 2 1/4 (5.7) 3 (7.6) 3 (7.6) 3 (7.6)
Floor to Center of Drain - in (cm) 6 (15.2)
4
11/16 (11.9) 5 (12.7) 6 5/8 (16.8)
Electrical Volts / Hz / Phase / Wiring/Distribution System Circuit Breaker Amps / Running Amps / Wire Size
230 / 50 / 1 / 2 wire + ground / TN-S 15 / 4 / 3.5 mm² 15 / 6.2 / 3.5 mm² 15 / 6.2 / 3.5 mm²
20 / 8.4 / 3.5
mm²
Installation Min. Clearance Between Machines - in (cm) 1/2 (1.3) 1/2 (1.3) 1/2 (1.3) 1/2 (1.3)
Min. Clearance Behind Machines - in (cm 24 (61) 24 (61) 24 (61) 24 (61)
Min. Concrete Thickness - in (cm) 6 (15.2) 6 (15.2) 6 (15.2) 8 (20.3)
Table 6-1 Vended Washer Specificaons
