Dexter Laundry T-650 - Floor Load Data

26
8514-300-001 REV PR
7.1.6 Floor Load Data
DEXTER DYNAMIC LOADING CHART
Model
Dry
Weight
Capacity
(lbs)
Extract
Speed
(RPM)
Extract G-
Force
Maximum
Static
Load (lbs)
Static
Load
Pressure
(lbs/sq ft)
Total
Dynamic
Load
(lbs)
Dynamic
Load
Pressure
(lbs/sq ft)
Dynamic
Load
Frequency
(Hz)
Maximum
Vertical
Load
(lbs)
Maximum
Moment
About
Washer
Base
(ft*lbs)
T-300 20 579 100 381 91 400 95 9.7 737 785
T-350 20 819 200 447 94 800 168 13.7 1203 1571
T-400 30 531 100 527 101 600 115 8.9 1062 1316
T-450 30 750 200 618 113 1200 220 12.5 1756 2631
T-600 40 531 100 686 97 800 113 8.9 1398 1754
T-650 40 750 200 882 134 1600 243 12.5 2384 3508
T-675 40 919 300 882 134 1600 243 15.3 2384 3508
T-750 50 685 200 1119 166 2000 297 11.4 2970 4667
T-900 60 485 100 1170 146 1200 149 8.1 2224 2800
T-350
SWD
20 819 200 864 128 800 118 13.7 1620 1571
T-450
SWD
30 750 200 1146 141 1200 148 12.5 2281 2238
Table 7-1 Dexter Dynamic Loading Chart
