Drive Motor Inverter Type
Motor-Winding Resistance Chart
T-650 O-Series Express Washer
Resistance
Motor Winding Wire # Minimum Maximum
T-650 1PH or 3PH 60Hz Main (wash & spin) T1 & T2 2.25 2.61
Dexter #9376-319-001 T2 & T3 2.25 2.61
T1 & T3 2.25 2.61
T-750 O-Series Express Washer
Resistance
Motor Winding Wire # Minimum Maximum
T-750 1PH or 3PH 60Hz Main (wash & spin) T1 & T2 .944 1.097
Dexter #9376-329-001 T2 & T3 .944 1.097
T1 & T3 .944 1.097
T-950 O-Series Express Washer
Resistance
Motor Winding Wire # Minimum Maximum
T-950 1PH or 3PH 60Hz Main (wash & spin) T1 & T2 .944 1.097
Dexter #9376-329-001 T2 & T3 .944 1.097
T1 & T3 .944 1.097
T-1450 O-Series Express Washer
Resistance
Motor Winding Wire # Minimum Maximum
T-1450 1PH or 3PH 60Hz Main (wash & spin) T1 & T2 .327
Dexter #9376-328-001 T2 & T3 .327
T1 & T3 .327
NOTE: Resistance values are measured at the stator. Values at the end of the motor wir-
ing harness may be slightly higher.
