Chapter 3
www.df .com
29
Chapter 3 BIOS Setup
Security Device Support
This field is used to enable or disable BIOS supporting f or the securit y device. O .S will
not show the securit
y device. T CG EFI protocol and INT1A interf ace will not be
available.
TPM State
This field is used to enable or disable the securit y device.
Pending operation
This field is used to schedule an oper ation for the securit y device.
Trusted Computing
This section configures set tings relevant to Trusted Computing innovations.
Enables or Disables
BIOS support for security
device. O.S. will not show
Security Device. TCG
EFI protocol and INT1A
interface will not be
available.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Confi guration
Security Device Support
TPM State
Pending operation
Current Status Information
TPM Enabled Status:
TPM Active Status:
TPM Owner Status:
Advanced
[Enable]
[Enabled]
[None]
[Enabled]
[Activated]
[Unowned]
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F4: Save & Reset
ESC: Exit
NCT6106D Super IO Configuration
This section is used to configure the par ameters of the system super IO chip .
Select AC power state
when power is re-applied
after a power failure.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
NCT6106D Super IO Confi guration
Super IO Chip
Restore AC Power Loss
WatchDog Timer Unit
Super IO WatchDog Timer

Serial Port 1 Confi guration

Serial Port 2 Confi guration

Serial Port 3 Confi guration

Serial Port 4 Confi guration

Serial Port 5 Confi guration

Serial Port 6 Confi guration
Advanced
NCT6106D
[Power Off]
[Second]
0
Restore AC Power Loss
Power Off
When power returns after an AC power failure, the system’s power is off. You must
press the P ower button to power -on the system.
Power On
When power returns after an AC power f ailure, the system will automatically power -on.
WatchDog Timer Unit
Selects the WatchDog Timer Unit: second or minute.
Super IO WatchDog Timer
Enter the v alue to set the Super IO W atchDog timer. 0 means disabled.
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F4: Save & Reset
ESC: Exit
Note:
Your computer will reboot during restart in order to change the device status.
