DFI BT253 - Page 30

Chapter 3
www.df .com
30
Chapter 3 BIOS Setup
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Serial Port 1 Confi guration
Serial Port
Device Settings
Change Settings
COM 1 Driver Mode
Advanced
[Enabled]
IO=3F8h; IRQ=4;
[Auto]
[RS232 driver]
Serial Port 1 Configuration to Serial Port 6 Configuration
Sets the par ameters of serial port 1 (COM A) and serial port 6 (COM F).
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F4: Save & Exit
ESC: Exit
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Advanced
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F4: Save & Exit
ESC: Exit
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Serial Port 3 Confi guration
Serial Port
Device Settings
Change Settings
COM 3 Driver Mode
Advanced
[Enabled]
IO=3E8h; IRQ=10;
[Auto]
[RS232 driver]
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F4: Save & Exit
ESC: Exit
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Serial Port 4 Confi guration
Serial Port
Device Settings
Change Settings
COM 4 Driver Mode
Advanced
[Enabled]
IO=2E8h; IRQ=11;
[Auto]
[RS232 driver]
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F4: Save & Exit
ESC: Exit
Serial Port 2 Confi guration
Serial Port
Device Settings
Change Settings
COM 2 Driver Mode
[Enabled]
IO=2F8h; IRQ=3;
[Auto]
[RS232 driver]
