Chapter 3
www.df .com
33
Chapter 3 BIOS Setup
SATA Configuration
This section is used to enable or disable S ATA devices.
Enable / Disable SATA.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
SATA Confi guration
Serial-ATA (SATA)
SATA Mode
Serial-ATA port 0
SA
TA Port 0 HotPlug
Serial-ATA port 1
SATA Port 1 HotPlug
Serial ATA Port 0
Not Present
Serial ATA Port 1
Not Present
Advanced
Serial-ATA (SATA)
This field is used to enable or disable Serial A TA devices.
Serial-ATA port 0 and port 1
Enable or disable Serial A TA port 0 and port 1.
Serial-ATA port 0 and port 1 HotPlug
Enable or disable Serial A TA port 0 and port 1 hotplug.
[Enabled]
[AHCI Mode]
[Enabled]
[Enabled]
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F4: Save & Reset
ESC: Exit
Network Stack Configuration
This section is used to enable or disable network stack set tings.
Enable/Disable UEFI
network stack.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Network Stack
Advanced
[Disabled]


Enter:
+/
-:
F1:
F2:
F4:
ESC:
Select Screen
Select Item
Select
Change Opt.
General Help
Previous Values
Save & Reset
Exit
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Network Stack
Ipv4 PXE Support
Ipv6 PXE Support
PXE boot wait time
Advanced
[Enabled]
[Enabled]
[Enabled]
0
Enable/Disable UEFI
network stack.


Enter:
+/
-:
F1:
F2:
F4:
ESC:
Select Screen
Select Item
Select
Change Opt.
General Help
Previous Values
Save & Reset
Exit
When Network Stack is set to enabled, it will displa y the f ollowing information:
