DFI BT253 - Page 35

Chapter 3
www.df .com
35
Chapter 3 BIOS Setup
USB Configuration
This section is used to configure the par ameters of USB device.
Enables Legacy USB
support. AUTO option
disables legacy support if
no USB devices are
connected. DISABLE
option will keep USB
devices available only for
EFI applications.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242 Copyright (C) 2013 American Megatrends, Inc.
USB Confi guration
USB Module Version
USB Devices:
1 Hub
Legacy USB Support
XHCI Hand-off
EHCI Hand-off
USB Mass Storage Driver Support
Advanced
8.11.01
[Enabled]
[Enabled]
[Enabled]
[Enabled]


Enter:
+/
-:
F1:
F2:
F4:
ESC:
Select Screen
Select Item
Select
Change Opt.
General Help
Previous Values
Save & Reset
Exit
Legacy USB Support
Enabled
Enable legacy USB
.
Disabled
Keep USB devices a vailable only f or EFI applications.
Auto
Disable support f or legacy when no USB devices are connected.
XHCI Hand-off
This is a workaround f or OSes without the XHCI hand-of f support. The change of XHCI
ownership should be claimed by the EHCI driv
er.
EHCI Hand-off
This is a workaround f or OSes without the EHCI hand-of f support. The change of EHCI
ownership should be claimed by the EHCI driv
er.
USB Mass Storage Driver Support
Enable or disable the support of the USB Mass Stor age Driver.
Important:
When installing Windows 7 , only nativ e USB 2.0 devices (USB port 0 to USB port 3)
can operate under DOS mode. Please ref er to the f ollowing tables for more inf omation
on the t ype of USB ports.
Operation
Environment
for Customers
DOS Windows 7 Windows 8.x Linux
OS Selection
in the BIOS
Advanced Menu
Windows 8.x Windows 7 Windows 8.x Windows 8.x
Available USB
ports
All
When installing Windows 7 f rst
time, only native USB 2.0 ports
can work. Please refer to the
USB type in table 2 below.
All All
Table 1. OS Selection
Model Name BT253
USB 3.0
Native
USB 0
Native
USB 1
Native
USB 2
Native (share with USB 3.0 port)
USB 3
Native
USB 4
HSIC port 0
USB 5
HSIC port 1
USB 6
HSIC port 2
USB 7
HSIC port 3
Table 2. The Type of USB Ports
