Chapter 3
www.dfi .com
27
Chapter 3 BIOS Setup
Main
The Main menu is the first screen that you will see when you enter the BIOS Setup Utility.
Advanced
The Advanced menu allows you to configure your system for basic operation. Some entries are
defaults required by the system board, while others, if enabled, will improve the performance
of your system or let you set some features according to your preference.
Important:
Setting incorrect field values may cause the system to malfunction.
Insyde BIOS Setup Utility
System Time
The time format is <hour>, <minute>, <second>. The time is based on the 24-hour
military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to
23. Minute displays minutes from 00 to 59. Second displays seconds from 00 to 59.
System Date
The date format is <day>, <month>, <date>, <year>. Day displays a day, from Sun-
day to Saturday. Month displays the month, from January to December. Date displays
the date, from 1 to 31. Year displays the year, from 1980 to 2099.
This is the help for the
hour, minute, second
fi eld. Valid range is from
0 to 23, 0 to 59, 0 to 59.
INCREASE/REDUCE:
+/-.
InsydeH20 Setup Utility
ExitSecurity
F1 Help ↑↓ Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit ←→ Select Menu Enter Select
SubMenu F10 Save and Exit
Project Name
BIOS Version
Processor Type
System Memory Speed
Cache RAM
Total Memory
Channel A - SODIMM 0
Channel B - SODIMM 0
System Time
System Date
BT55x
57.230
Intel(R) Atom(TM) CPU E3845 @1.91GHz
1333 MHz
2048 KB
4096 MB
2048 KB
2048 KB
[10:43:29]
[09/01/2015]
Advanced
Power Boot
Main
Rev. 5.0
Confi gures Boot Settings
Boot Confi guration
PCI Express Confi guration
Audio Confi guration
Miscellaneous Confi guration
Security Confi guration
Video Confi guration
SATA Confi guration
SIO NUVOTON6106D
Main
Advanced
F1 Help ↑↓ Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit ←→ Select Menu Enter Select
SubMenu F10 Save and Exit
InsydeH20 Setup Utility
ExitSecurity Power Boot
Rev. 5.0
To Next Page
