Chapter 1 - Introduction
Specifications
Chapter 1
Chapter 1 Introduction www.dfi .com
Note:
*Optional and is not supported in standard model. Please contact your sales represen-
tative for more information.
I/O Connectors
• 2 connectors for 4 external USB 2.0 ports
• 3 connectors for 3 external serial ports (2.0mm pitch)
- 1 RS485
- 2 RS232
• 1 LVDS LCD panel connector
• 1 LCD/inverter power connector
• 1 8-bit DIO connector
• 1 DIO power connector
• 1 front audio connector for line-out and mic-in jacks
• 1 LPC connector
• 1 SMBus connector
• 1 Serial ATA connector
• 1 Serial ATA power connector
• 1 front panel connector
• 1 chassis intrusion connector
• 1 fan connector
Energy Effi cient
Design
• Supports ACPI
• System Power Management
• Wake-On-Events include:
- Wake-On-USB KB/Mouse* (optional)
- Wake-On-LAN
- RTC timer to power-on the system
• AC power failure recovery
Damage Free
Intelligence
• Monitors CPU/system temperature and overheat alarm
• Monitors VCORE/12V/5V/DDR voltages and failure alarm
• Monitors system fan speed and failure alarm
• Read back capability that displays temperature, voltage and fan speed
Power
Consumption
• TBD
OS Support
• Windows 7 Ultimate x86 & SP1 (32-bit)
• Windows 7 Ultimate x64 & SP1 (64-bit)
• Windows 8.1 Embedded Pro x86 (32-bit)
• Windows 8.1 Embedded Pro x64 (64-bit)
Temperature
• Operating (TBD)
: 0
o
C to 60
o
C - Atom, Celeron (Fanless)
: -20
o
C to 70
o
C - Celeron (Fanless)
: -40
o
C to 85
o
C - Atom (Fanless)
• Storage: -40
o
C to 85
o
C
Humidity
• 5
o
C to 90
o
C
Dimensions
• 3.5" board
• 146mm (5.75") x 102mm (4.02")
Certifi cation
CE, FCC Class B, RoHS
Processor
• Intel
®
Atom
TM
/
Intel
®
Celeron
®
processors
E45:
Intel
®
Atom
TM
E3845, Quad Core, 2M Cache, 1.91GHz, 10W
E26: Intel
®
Atom
TM
E3826, Dual Core, 1M Cache, 1.46GHz, 7W
J00: Intel
®
Celeron
®
J1900, Quad Core, 2M Cache, 2GHz (2.41GHz), 10W
• BGA 1170 packaging technology
• 22nm process technology
Super I/O
Address
• NCT6106/4Eh
System Memory • 2GB/4GB DDR3L memory down
• Supports DDR3L 1066/1333MHz
• Supports dual channel memory interface
Expansion
Interface
• 1 Mini PCIe slot
- Supports USB and PCIe signals
- Supports full size Mini PCIe card
Graphics
• Intel
®
HD Graphics
• Display ports: 1 VGA, 1 LVDS, 1 DP
• VGA: 24-bit, resolution up to 2560x1600 @ 60Hz
• LVDS: NXP PTN3460, 24-bit, dual channel, resolution up to 1920x1200 @ 60Hz
• DP: supports DP++, resolution up to 2560x1600 @ 60Hz
• Supports hardware acceleration for DirectX 11, OCL 1.2, OGL 4.0, H.264,
MPEG2, MVC, VC-1, WMV9 and VP8 (supported version dependent on OS)
Audio
• Realtek ALC888 2.1-channel High Defi nition Audio
LAN
• 2 Intel
®
I210 PCI Express Gigabit Ethernet controllers
• Integrated 10/100/1000 transceiver
• Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Serial ATA
• 1 SATA 2.0 port with data transfer rate up to 3Gb/s
• Integrated Advanced Host Controller Interface (AHCI) controller
eMMC*
(optional)
• Supports 8GB, 16GB and 32GB eMMC onboard
• Supports Windows 8.1 only
Trusted
Platform
Module - TPM*
(optional)
• Provides a Trusted PC for secure transactions
• Provides software license protection, enforcement and password protection
WatchDog Timer
• Watchdog timeout programmable via software from 1 to 255 seconds
Rear Panel I/O
Ports
• 1 12V (BT551) or 15~36V (BT553) DC-in jack
or 4-pin power connector* (optional)
• 1 DP port
• 1 VGA port
• 2 RJ45 LAN ports
• 1 USB 3.0 port
• 1 USB 2.0 port
BIOS
• Insyde BIOS
- 64Mbit SPI BIOS
