MODEL BMG-535 GRINDER
SECTION 5 INITIAL OPERATION
37
OPERATING MANUAL
APRIL 2009
Grinding & Polishing
Fig. 5.1
Switching on the grinding machine:
• Make sure the motor is connected to the plug on the bottom of the panel
with the supplied cord.
• Make sure the electrical disconnect switch (2) on the outside of the panel
is turned to the off position.
• Connect the machine to the electrical outlet (1) with an extension cable
that complies with the appropriate European or U.S. NEC guideline, as
appropriate.
• Turn the electrical disconnect switch (2) on the outside of the panel to the
“ON” position.
• Put the safety cord on to your wrist and make sure the other end is inserted
into the SAFETY SWITCH (3).
• Press down both handgrips (4) until the front part rises approximately 4
inches (10 cm) from the ground.
5.2 INITIAL OPERATION
