Diamatic BMG-535 - Electrical Schematic - 230 V; 50 and 60 HZ

MODEL BMG-535 GRINDER
SECTION 8 MAINTENANCE
58
Grinding & Polishing
OPERATING MANUAL
APRIL 2009
To identify electrical components, refer to the electrical schematics in
Section 8.2 or call a service center.
8.1 DIRECTIONS FOR ELECTRICAL ENGINEERING
Work on electrical equipment or operating materials may only be
performed by a skilled electrician or by trained persons under the
guidance and supervision of a skilled electrician as well as in
accordance with the electrical en
g
ineerin
g
re
g
ulations.
The results of all electrical repair work must be verified using the
appropriate measurement techniques per the regulations stated
in the European VBG4 and VDE 0701 standards or per the
applicable U.S. guidelines, as appropriate. See also Section 5.2
Initial operation.
