4 Parts List
ECO 9099 SOP05-5090F Rev.00 Effective Date: 12/20/18 Page 58 of 58
4. Parts List
4.1. Consumables
Replacement Part #
Description
Warranty
AV-BP0413D ELECTRODE, Na
+
12 months
AV-BP0359D ELECTRODE, K
+
6 months
AV-BP0570D ELECTRODE, Cl
-
6 months
AV-BP0360D ELECTRODE, Ca
++
6 months
AV-BP0962D ELECTRODE, Li
+
3 months
AV-BP5026D
ELECTRODE, REFERENCE
12 months
AV-BP5027D
PERISTALTIC PUMP TUBING
3 months
AV-BP5193D
PINCH VALVE TUBING KIT
6 months
AV-BP5186D
FLUID PACK
Use before expiration date
AV-BP0380D
NA ELECTRODE CONDITIONER SOLUTION
Use before expiration date
AV-BP1025D
CLEANING SOLUTION
Use before expiration date
AV-BP0521D
DEPROTEINIZER SOLUTION
Use before expiration date
AV-BP0344D
URINE DILUENT
Use before expiration date
AV-BP5025D
THERMAL PRINTER PAPER
Replace as necessary
AV-BP5019D
REFERENCE ELECTRODE HOUSING
Replace as necessary
AV-BP5006D
SAMPLE PROBE
Replace as necessary
4.2. Analyzer Parts for Repair
Replacement Part #
Description
CN-A4010
ASPIRATION ASSEMBLY
CN-A4060
PRINTER GRAPHIC ASSEMBLY,
CN-4022
BASE, ISE ELECTRODE TRAY, SmartLyte
®
Plus
CN-A4405
BOARD, CPU, SmartLyte
®
Plus
CN-A4406
BOARD, DISPLAY, SmartLyte
®
Plus
CN-A4054
BOARD, RFID
CN-A4018
BOARD, VPB
CN-4431
CPU INTERFACE, SmartLyte
®
Plus
CN-4155
CRIMP PIN
CN-A4411
ELECTRODE TRAY, SUBASSEMBLY, SmartLyte
®
Plus
AV-BP9043D
FILLPORT ASSEMBLY /9100
CN-4018
INDICATOR CAP
AV-BP5014D
KIT, SHUTDOWN
AV-BP5194D
KIT, STARTUP
AV-BP5027D
PERISTALTIC PUMP TUBING
AV-BP5193D
PINCH VALVE TUBING KIT
CN-A4012
PUMP MOTOR, PERISTALTIC, SUBASSEMBLY
CN-A4014
ROTOR, PERISTALTIC PUMP, SUBASSEMBLY
AV-BP5036D
SAMPLE SENSOR
CN-A4415
SD CARD, SMARTLYTE PLUS
CN-A4409
SUBASSEMBLY, POWER SUPPLY, SmartLyte
®
Plus
CN-4070
TRAY, PRINTER PAPER
CN-A4015
VALVE, SOLENOID, SUBASSEMBLY
