Digi XBee Getting Started Guide

©2011DigiInternational,Inc.. 17
XBee Wi‐Fi Development Kit Getting Started Guide
15.SelecttheTerminaltabforeachmodule,clickanywherewithinthewhitewindow,andtypeany
charactersthatyouwouldliketheXBeeWi‐Fimoduletotransmit.

Note:Typedcharactersinthewindowofonemodulewillbetransmittedtotheother
moduleanddisplayedinthatmodulesX‐CTUscreen.Characterstransmittedaredisplayed
inbluetextandcharactersreceivedaredisplayedinredText.
YouhavejustcompletedGoal#3‐usingX‐CTUtoestablishan
802.11bgnnetworkconnectionbetweentheXBeemodules,
usingaccesspointsorawirelessrouter.

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
