XBee Wi‐Fi Development Kit Getting Started Guide
Assemble your XBee Wi-Fi Development Kit
AssemblethekitbyplacingoneXBeeWi‐FimoduleoneachoftheXBeeUSBDevelopmentBoardsas
showninthediagrambelow.ConnecttheU.FLantennatotheU.FLXBeeasshown.ConnecttheUSB
cabletotheXBeeUSBDevelopmentBoard;itwillbeattachedtothecomputer
inalaterstep.
Notes:
1.TheantennaisonlyinstalledonU.FLmodules.ThePCBantennamodulecomesequipped
withanantennaalreadyonthemodule.
2.ModulesareinstalledbyaligningpinsandpressingintotheXBeeUSBDevelopmentBoard
socket.
3.ModulescanberemovedfromtheXBeeUSBDevelopmentBoardsocketbycarefully
applyingupwardpressuretothemodule.
4.Thepowersupplyjackisonthelowerleftcorneroftheboard.Itisnotrequiredforthis
module.ThisguideassumestheboardispoweredbyaUSBcableconnectedtothe
computer.
YouhavejustcompletedGoal#1‐settingupyourXBee
Wi‐FiDevelopmentKit.
or

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
