DigiCare DigiPump LP8 - Rear View; Bottom Components

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc.
- 8 -
1.4.5 Rear view
1.4.6 Bottom components
Drop detector: Place it at
this point when it is not in
use.
Adjust for Occlusion
Pressure, Air IN Line
alarm sensitivity and
Alarm volume
AC Power receptacle: Class II
type CF, Drip-proof design
AC power switch: Class
II,type CF, Drip-proof
design
Pole Mount
Auto Adjust: Press the key
to adjust the IV set
automatically.
Drop detector
receptacle
Battery compartment
Remove the screw to access
the battery
Battery
Battery Compartment
Fixation nip at the bottom:
when there are many infusion
pumps working at the same
time, you can fix these pumps
on the bar through the nip.
